Study on the Vehicle-Bridge Coupling Vibration of Steel Arch Bridge

Abstract:

The modal analysis and the calculation of dynamic response of the Fenghua Bridge, a new type of long-span steel arch bridge, are carried out using the finite element software ANSYS. Through the on-site testing, the vibration frequency and the change of dynamic displacement response with different weight and speeds are obtained by the DASP data processing software. It is found that the field test results are in consistent with the theoretical results. Firstly, the natural vibration period is 2 ~ 3 times longer than the other ordinary arch bridges, which indicate the bridge structure is stable; Secondly, the dynamic displacement of bridge deck changes in the same direction with weight, while in the opposite direction with speed, and the maximum appears on the midpoint of the middle span; Finally, the maximum dynamic displacement is 11.41mm, which doesn’t exceed the allowable value. So it can be concluded that the bridge is safe under the vehicle-bridge coupling vibration.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 233-238
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.233
• Online since: December 2010
• Authors: Zi Lin Li, Pei Yuan Zhou, Zhen Bo Yun
• Keywords: Dynamic Response, Modal Analysis, Steel Arch Bridge, Vehicle-Bridge Coupling

References

[1] Wusong Weng: China Railway Science, 2005(9): 3-4. (in Chinese).

[2] Guanghua Wu: Dynamic work performance analysis of highway bridge based on vehicle-bridge coupling vibration [D]. Harbin: Harbin Institute of Technology, 2007. (in Chinese).

[3] HENCHI K, FAFARD M, TALBOT M, et al: Sound and Vibration, 1998, 212(4): 663—683.

[4] GB50017-2003 Code for design of steel structure[S]. (in Chinese).

[5] JTG—2004 General Code for Design of Highway Bridges and Culverts[S]. (in Chinese).

[6] Jiao Chen: Analyzing vehicle-bridge coupled vibration of simple beam bridge subjected to moving loads [D]. Hefei: Hefei University of Technology, 2009. (in Chinese ).

[7] Wei Li: ANSYS Application Instance of Civil Engineering [M]. Beijing: China Waterpower Press, 2007. (in Chinese).

[8] Baochun Chen: The Concrete Filled Steel Tube Arch-bridge [M]. Beijing: People's Transportation Press, 2007. (in Chinese).

[9] COINV, DASP-ET engineering software manuals, 2007. (in Chinese).

[10] Yi Tang: Visual simulation on vehicle vibration of rigid-framed arch bridge [D]. Fuzhou: Fuzhou University, 2003. (in Chinese).

[11] CJJ-1998 The Standard of Loadings for the Municipal Bridge Design[S]. (in Chinese).
