The Effect of Plate-Plate Butt Welding Stress Distribution on the Welding Deformation

Abstract:

In this paper, the distribution of residual stress is measured which is 60mm away from the weld center with the three-dimensional magnetic measurement apparatus of HZ-21. The stress distribution of plate - plate butt welding and its influence on welding deformation are studied. The results show that, plate - plate butt of Q235B steels, the welding stress distribution of σx direction is in the direction of a curve along the seam; 24 hours after welding, the welding angular deformation increases due to the changes of welding stress, while welding angular deformation also changes the stress distribution.

• Periodical: Advanced Materials Research (Volumes 189-193)
• Pages: 3517-3520
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.189-193.3517
• Online since: February 2011
• Authors: Tao Yuan, Zhen Luo, Hui Luo
• Keywords: Angular Deformation, Plate-Plate Butt, Q235B Steel, Residual Stress

References

[1] Bin-shi Xu. In Chinese. China's steel industry enter into the golden period of development and reach up to international standards [J]. China Construction News. November, (2004).

[2] Xiaomin Gao. In Chinese. The control of welding distortion [J]. Welding, 2007: 63-64.

[3] Zongjie Wang, Ruheng Zang, Deyuan Li. In Chinese. Q&A of welding technology of engineering Materials [M]. Beijing: Mechanical Industry Press , August, 2002: 240-255.

[4] Zhongqi Cui, Yaochun Qin. In Chinese. Metallurgy and heat treatment [M]. Beijing: Mechanical Industry Press , 2007: 280-319.

[5] Lee, CH, Chang, KH. Numerical investigation of the residual stresses in strength-mismatched dissimilar steel butt welds [J]. The Journal of Strain Analysis for Engineering Design, 2008, vol. 43 (no. 1).

DOI: 10.1243/03093247jsa313

[6] Huijie Liu. In Chinese. Welding metallurgy and weldability [M]. Beijing: Mechanical Industry Press , March, 2007: 164-172.
