Finite Element Analysis on the Influence of Back-Up Ring on the Sealing Effect of Rubber O-Ring

Abstract:

Based on finite element analysis software ANSYS, the deformation and force condition of the rubber sealing o-ring pre and post with back-up ring under different oil pressure conditions was analyzed. The von mises stress distribution of the o-ring and the change of contact pressure between o-ring and sealing interface pre and post with back-up ring under different oil pressure conditions were discussed. The results show that, the maximum von mises stress of the o-ring is smaller and the maximum von mises stress of the sealing system concentrates on the left top and the right bottom of the back-up ring after using it; the o-ring will not be extruded into the gap of the groove because of the existence of back-up ring which prevents gap-bite and prolongs service life of the o-ring; the contact pressure between o-ring and sealing interface increased, thus the sealing reliability of the system increased.

• Periodical: Advanced Materials Research (Volumes 199-200)
• Pages: 1595-1599
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.199-200.1595
• Online since: February 2011
• Authors: Dian Xin Li, Hong Lin Zhao, Shi Min Zhang, Chang Run Wu, Xian Long Liu, Shan Jun Zheng
• Keywords: Back-Up Ring, Finite Element Model (FEM), Rubber O-Ring, Sealing Effect, Stress Distribution

References

[1] B.Z. GUO, B.F. SONG, F.G. SUN and W.M. CUI: Chinese Hydraulics & Pneumatics, Vol. 32 (2009) No. 1, pp.31-34. (In Chinese).

[2] W. Wang and S.G. Zhao: Lubrication Engineering, Vol. 30 (2005) No. 4, pp.106-108. (In Chinese).

[3] F.C. Shang, J.H. Rao, Q.F. Shen and F.C. He: Chinese Hydraulics & Pneumatics, Vol. 33 (2010) No. 1, pp.67-70. (In Chinese).

[4] J. Wang and Y.J. Xie: Journal of Liaoning University of Petroleum & Chemical Technology, Vol. 28 (2008) No. 4, pp.48-57. (In Chinese).

[5] R.S. Rivlin and D.W. Saunders: Philosophy Transaction of Royal Society, 1951, A243: 289-298.

[6] I Fired and A.R. Johonson. Computer Methods in Applied Mechanics and Engineering, 1998, 67: 241-253.

[7] W. Wang, T. Deng and S.G. Zhao. Special Purpose Rubber Products, Vol. 25 (2004) No. 4, pp.8-10. (In Chinese).

[8] R.D. Liao, Z.X. Zuo and W.S. Zou. Lubrication Engineering, Vol. 11 (1996) No. 5, pp.30-33. (In Chinese).

[9] G.Q. Liu and Q.D. Yang: tutorial of Engineering application (Trans Tech Publications, China 2003). (In Chinese).

[10] Q.W. Wang, F. Zuo and R.X. Hu: ANSYS10. 0 mechanical design senior application examples (Trans Tech Publications, China 2006). (In Chinese).
