FEM Analysis of an Amphibious Hydraulic Excavator’s Boom and Stick

Abstract:

Force conducted to boom and stick is analyzed by complicated elements divide of FEM, it shows that the more the box section is, the more load is, and Hinge point’s force is much more than before. If size isn’t be affected, it can be reduced by increasing the sectional area. FEM analysis and design comparison analysis results show that FEM analysis method is feasible to amphibious hydraulic excavator. FEM analysis of results to practical design provides a practical way and means for the process of other construction machinery design analysis.

• Periodical: Advanced Materials Research (Volume 215)
• Pages: 336-339
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.215.336
• Online since: March 2011
• Authors: F.R. Tian, Z.C. Han
• Keywords: BOOM, Complicated Element Divide, Excavator, Finite Element Model (FEM), Stick

References

[1] D. W. Kong, K. L. Zhao: Hydraulic Excavator. (Chemistry Industry Press, Beijing, 2007).

[2] M. L. Zhou: Machinery Products and Science & Technique, (1997), pp.2127-2130.

[3] S. Yu, J. Z. Zhang: Construction Machinery, (2002), pp.8-10.

[4] S. H. Cao, H. Yu: Single Dipper Hydraulic Excavator. (Chinese Architecture Industry Press, Beijing, 1986).

[5] Q. S. Fan, Y. J. Yin: Materials Mechanicals. (Tsinghua University Press, Beijing 2004).

[6] K. Liu: ANSYS FEM Concise Explanation. (Defense Industry Press, Beijing, 2005).

[7] F. C. Wang, C. H. Zhang: ANSYS10. 0 FEM Analysis and Application in Engineering. (Electronic Industry Press, Beijing, 2006).
