Direct Writing of Channels for Microfluidics in Silica by MeV Ion Beam Lithography

Abstract:

The lithographic exposure characteristic of amorphous silica (SiO₂) was investigated for 6.8 MeV ¹⁶O³⁺ ions. A programmable proximity aperture lithography (PPAL) technique was used for the ion beam exposure. After exposure, the exposed pattern was developed by selective etching in 4% v/v HF. Here, we report on the development of SiO₂ in term of the etch depth dependence on the ion fluence. This showed an exponential approach towards a constant asymptotic etch depth with increasing ion fluence. An example of microfluidic channels produced by this technique is demonstrated.
