The Application in TheTubular Furnace Control System Based on OPC Technology

Abstract:

In the industry of petrochemical, tubular furnace is a kind of energy-consumption device, therefore it appears especially significant for its controlling. Usually, it adopts kingview software for simple monitoring, which hardly lowers consumption. Moreover, because of the limitation of compiling control arithmetic, it becomes unrealistic for complicated control requirements. While MATLAB is equipped for powerful function of numerical analysis and computing, it can accomplish the designation for the complex intelligent controller and data analysis processing. The two complement each other can realize the real-time control of combining Kingview with MATLAB, but the key technology is to realize the real-communication of them. In this paper, OPC technology based on the standard interface is illustrated, and on this basis, the program of the real-communication between King view and MATLAB based on OPC is introduced. The thesis takes tubular furnace temperature control before and after preheating for example, and finally proves the advantages complementation between kingview and MATLAB, which supplies an efficient path for realizing complex control arithmetic.

• Periodical: Advanced Materials Research (Volumes 268-270)
• Pages: 616-619
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.268-270.616
• Online since: July 2011
• Authors: Zai Ping Chen, Xing Jun Li
• Keywords: King View, MATLAB, OPC, Tubular Furnace

References

[1] D. W. Holley, Understanding and Using OPC for maintenance and reliability applications, Journal, IEEComputing and control engineering, Mar. (2003).

[2] M. Wollchlaeger, P. Neumann and Th. Bangemann, Web service for remote maintenance of fieldbus based automation systems, IEEE-AFRICON, Oct. (2002), pp.247-252.

DOI: 10.1109/afrcon.2002.1146842

[3] OPC FOUNDATION, OPC UA Part 3-Address Model Space. Versio1. 00 July 28, (2006).

[4] Guo Weihe , Du Dewen. Application of OPC Technology in Energy Resources Network and PLC System Data Traffic, , Laigang Science & Technology, Vol. 1(2008), pp.27-29.

[5] Gao Fei. Application of OPC Technology in Enterprise Integrated Automation, Nansteel Science Technology and Management, Vol. 3 (2008), pp.49-51.

[6] DUAN Dequan, LI Junfen. Real-Time Data Integration System Based on OPC, Computer Era, Vol. 7 (2009), pp.33-36.

[7] Wu Mingyong; Wang Guowei. Intelligent Control System of Boiler Drum Water Level Based on OPC Technology and MATLAB, Computer Measurement & Control, Vol. 10(2010), pp.2296-2298.
