Parametric Design of Wet Shifting Clutch Based on Secondary Development of Pro/E

Abstract:

In order to meet the design requirements, the wet shifting clutch was designed based on secondary development of Pro/E. The basic principle of parametric design and the system composition of Pro/Toolkit application program were introduced. The three-dimensional template of wet shifting clutch was established. The VC++6.0 programming platform was utilized. The application program interface was set up by using the synchronous mode of Pro/Toolkit. The regeneration of wet shifting clutch was completed. The parametric design about the key sizes in the key parts and assembly relationship of the wet shifting clutch were realized. The convenient design of wet shifting clutch was achieved. The effective method could be provided for the parametric design of other complex parts.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 2195-2200
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.2195
• Online since: August 2011
• Authors: Hong Wei Cui, Qing Dong Yan, Shou Wen Yao
• Keywords: Parametric Design, Pro/E Secondary Development, Pro/Toolkit, Wet Shifting Clutch

References

[1] Gao, H., G. C. Barber,M. Shillor. Numerical Simulation of Engagement of a Wet Clutch With Skewed Surface Roughness[J]. Journal of Tribology, 2002, 124 305-312.

DOI: 10.1115/1.1402178

[2] Jafri, Firoz Ali. Nonlinear Dynamics of Controlled Slipping Clutches[D]. CINCINNATI: UNIVERSITY OF CINCINNATI, 2007.

[3] Yaofei, Chen, Yang Yalian,Qin Datong. Analysis on Overall Heat Transfer Process of Multi-disk Wet Clutch[J]. Journal of Chongqing Institute of Technology(Natural Science), 2009, 23 (5): 11-16. （in Chinese）

[4] Yijun, Peng, Gong Chunquan, Yan Zhongsheng, et al. Study on Parametric Design and Simulation Analysis System for Clutch[J]. Diesel Engine, 2010, 32 (1): 49-52. （in Chinese）

[5] Guojin, Chen, Yan Xiaomin, Chen Chang, et al. Parameter modeling technology of automotive clutch based on secondary development of Pro /E[J]. Mechanical&Electrical Engineering Magazine, 2008, 25 (11): 87-90. （in Chinese）

[6] Chunquan, Gong, Yan Zhongsheng, Chang Zhenluo, et al. Study on a parametric design and simulation analysis system of a heavy-duty friction synchronous clutch[J]. Ship Science and Technology, 2010, 32 (8): 185-189. （in Chinese）

[7] Lijun, Wu,Chen Bo. The Base of Pro/ENGINEER Secondary Development Technology[M]. Beijing: Publishing House of Electronics Industry, 2006: （in Chinese）

[8] Shiguo, Li. The Design of Pro/TOOLKIT Program [M]. Beijing: Mechanical Industry Press, 2003:

[9] Shucheng, Liu,Yan Qingdong. Parametric Design for a One-way Roller Clutch with Logarithmic Spiral Surface[J]. Vehicle&PowerTechnology, 2010, (118): 36-40. （in Chinese）

[10] Qiongfeng, Mei, Yan Zhongsheng, Gong Chunquan, et al. A Clutch Parametric CAD Systerm based on the Pro/E[J]. Journal of Mechanical Transmission, 2009, 33 (1): 61-64. （in Chinese）
