Self-Development Design of Automotive Transmission Based on MASTA Platform

Abstract:

MASTA is the professional CAE software for auto transmission simulation, analysis and design system. Based on this, firstly how to realize the design and optimization of auto transmission assembly is discussed by MASTA system deflection analysis principle, not only are the accuracy of gear strength and modification analyzed through comparison, but also the selection and rating basis of axis and bearing are obtained. In addition, on basis of the full consideration of the whole structure deflection namely the structural flexibility factor, the influence of the housing and alien shafts’ actual rigidity on internal driving system is checked, and the analysis results of gear strength are presented. A new design concept is put forward, which improves design level of gearbox, and reduces the testing time and shortens the product development cycles as well.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 2201-2204
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.2201
• Online since: August 2011
• Authors: Yan Lin Tian, Jing Liang He, Hao Long Niu
• Keywords: Auto Transmission, MASTA, Structural Flexibility, System Deflection

References

[1] Rongxia Wang, The application of MASTA software: Journal of Automobile gear technology. Vol. 1(2008), p: 22-23. (In Chinese)

[2] Hongbin Xu, Peng Jia and Peijun Li, Research on gear tooth surface's contact area of transmission based on FE software MASTA: Product development and design. Vol. 6(2006), p: 45-47. (In Chinese)

[3] Zhenguo Shang, Hui Liu, Zhongdong Xie, et al. The principle and application of gear modification: Journal of Dalian Fisheries University. Vol. 24(2009), (supplement): Vol. 5(2009), p: 220-221. (In Chinese)

[4] Shaopeng Tian, Chen Tang, Fuwu Yan, et al. Gear mesh of mini transmission based on MASTA: Automotive engineer.Vol.5(2010), p: 30-34. (In Chinese)
