Finite Element Analysis for Pin-Hole-Output Mechanism of FA Cycloid Drive Based on ANSYS

Abstract:

In order to validate the pin-hole-output mechanism of FA cycloid drive force analysis theory, and based on the study on the basis of the contact problem, this article used the international advanced finite element analysis software ANSYS, established the output dowel pin and cycloid gear pin hole's contacting finite element model, and analyzed the static three-dimensional contact analysis. The calculation results coincided with the proposed pin-hole-output mechanism with gap dynamic stress analysis method, proved the correctness of the stress analysis theory.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 2220-2223
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.2220
• Online since: August 2011
• Authors: Lei Lei, Ying Tao, Tian Min Guan
• Keywords: FA Cycloid Drive, Finite Element Analysis (FEA), Pin-Hole-Output Mechanism
