Simulation and Analysis of Dynamical Transmission Precision of 2K-V Cycloid pin Gear Reducer Based on Multi-Body System Dynamics

Abstract:

The dynamic model of multi-rigid-body system and rigid-flexible coupling system of 2K-V cycloid pin gear reducer are constructed with ADAMS, the output-angle error curves are obtained by multi-body system dynamic simulation, and the influence of elastic deformation come from planet gear, cycloid gear and pin gears on the transmission accuracy are analyzed. The work this paper introduced provides a useful approach for further study on the dynamic transmission accuracy of precision gear drive system, exploration of active control technology for the transmission accuracy and improvement of structural design for the gearing.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 2205-2210
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.2205
• Online since: August 2011
• Authors: Bin Zhu, Wei Qin, Jin Liu, Yuan Lei Fu
• Keywords: 2K-V Cycloid pin Gear Reducer, Multi-Body System Dynamics, Transmission Precision

References

[1] Li C., Liu J. and Sun T: Study on Transmission Precision of Cycloidal Pin Gear in 2K-V Planetary Drives. Chinese Journal of Mechanical Engineering, Vol. 37(4), pp.61-65, (2001)

DOI: 10.3901/jme.2001.04.061

[2] Guo HaiJun: The Analysis and Simulation of 2K-V Type Cycloid Pin Gear Transmission Accuracy. Master Dissertation, School of Mechanical Engineering, Northwestern Polytechnical University, China, (2005)

[3] Teruaki HIDAKA, Hongyou WANG, Takeshi ISHIDA, Kazuyuki MATSUMOTO and Masataka HASHIMOTO: Rotational Transmission Error of K-H-V Planetary Gears with Cycloid Gear (1st Report, Analytical Method of the Rotational Transmission Error). JSME International Journal SERIES C, Vol. 60(570), pp.645-653, (1994)

DOI: 10.1299/kikaic.60.645

[4] Takeshi ISHIDA, Hongyou WANG, Teruaki HIDAKA and Masataka HASHIMOTO: Rotational Transmission Error of K-H-V-Type Planetary Gears with Cycloid Gears (2nd Report, Effects of Manufacturing and Assembly Errors on Rotational Transmission Error). JSME International Journal SERIES C, Vol. 60(578), pp.3510-3517, (1994)

DOI: 10.1299/kikaic.60.3510

[5] Han Linshan., Shen Yunwen., Dong Haijun., et al: Research on the Transmission Accuracy for Cycloid Drive Based on the Nonlinear Analysis Method. China Mechanical Engineering, Vol. 18(9), pp.1039-1042, (2007)

[6] Han Linshan., Shen Yunwen., Dong Haijun., et al: Theoretical Research on Dynamic Transmission Accuracy for 2K-V-type Drive. Chinese Journal of Mechanical Engineering, Vol. 18(9), pp.81-86, (2007)

DOI: 10.3901/jme.2007.06.081

[7] Han Linshan., Shen Yunwen., Dong Haijun., et al: Manufacturing Errors on Transmission Accuracy for 2K-V-Type Drive. Mechanical Science and Technology, Vol. 26(9), pp.1135-1440, (2007)

[8] Zhu Bin., Qin Wei., Sun Wei., Liu Jin: Dynamic Revolution and Transmission Error Analysis of 2K-V Cycloidal-pin Planetary Gear Speed Reducer. Journal of Mechanical Transmission, Vol. 35(4), pp.12-15, (2011)

[9] Li Lixing, He Weidong, Li Xing, Ye Qingtai, Zhu Xiaolu, in: Gear Transmission Design Manual, edited by Zhu Xiaolu/ Chemical Industry Press, China, (2007)
