Effect of the Process Parameter on as-Cast 30Cr2Ni4MoV Steel Soundness during Cogging

Abstract:

As-cast 30Cr2Ni4MoV steel was researched quantificationally to obtain the distribution and pattern of the microcosmic defect. By means of finite element simulation and experiment research, porosity consolidating and relative density evolution of as-cast 30Cr2Ni4MoV steel were investigated for a FM stretching process at a constant strain rate 0.001s-1. The studied parameters included three temperatures (800°C, 1000°C, 1250°C) and three deforming passes(1,2,3) and three friction factors(0.3,0.5,0.7), which bracketed the parameters that were used during most primary break-down processes. Temperature had an obvious effect on the porosity consolidating, but friction factor had no effect on the ultimate soundness nearly. When beginning temperature was 1250°C and heat exchanged considered, initial porosity can be eliminated after the accumulated effective strain reached 1.0 at least. The residual defect of the wrought material at different strain lever was compared to the initial defect of as-cast material and found to be somewhat reduced. The impact toughness of the wrought material at different strain lever was also compared to the as-cast material and found to be obvious improved. The difference in these behaviors between as-cast and wrought material could be attributed to the healing of the porosity defect and the enhancement of the soundness at a certain extent.

• Periodical: Advanced Materials Research (Volumes 314-316)
• Pages: 789-793
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.314-316.789
• Online since: August 2011
• Authors: Hong Ping An, Jian Sheng Liu, Jian Guo Wu
• Keywords: As-Cast 30Cr2Ni4MoV Steel, Defect Evolution, Ingot-Forging, Process Parameter, Soundness

References

[1] J.P.immarigeon, Krishna rajan, and W.wallace . Microstructural changes during isothermal Forging of a Co-Cr-Mo Alloy. Journal of Metallurfical transactions A, 1984,15A(2):339-345.

DOI: 10.1007/bf02645120

[2] Martin C. Mataya, Eric R. Nilsson, Elliot L. Brown, and George Krauss, Hot Working and Recrystallization of As-Cast 316L. Journal of Metallurgical and Materials transactions A, 2003, 34A(8).pp.1683-1703

DOI: 10.1007/s11661-003-0313-8

[3] Ren Yun-lai, Nie shao-min, Chen ying.Study on porousity collapse factor of large forging. Chinese journal of mechanical engineering, 2003,. 39(3), pp.126-129. In Chinese.

DOI: 10.3901/jme.2003.03.126

[4] Li Wei-min. Study on consolidating effect of loose structure by using new FM forging process. Journal of heavy casting and forging, 1998, (3):pp.10-14. In Chinese.
