Design of 3D Integrated Structure with Vertical Honeycombed-Core

Abstract:

In order to study the influences of fabric specification on vertical depth of honeycomb weaves, 11 kinds of honeycomb weaves fabric were designed in this paper by using different yarn linear density and weave repeat unit. The results show that the vertical depth of honeycomb weaves would increase as the yarn linear density increasing when the linear density was comparatively larger. With the increasing of weave repeat unit, vertical depth of honeycomb weaves is significantly increased. According to these results, 3D integrated vertical structure with honeycombed-core was designed, which used honeycomb weaves as the sandwich structure and plain weaves as the upside face and underside face. At the same time, the looming draft of this structure was drawn.

• Periodical: Advanced Materials Research (Volumes 332-334)
• Pages: 985-988
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.332-334.985
• Online since: September 2011
• Authors: Cheng Yan Zhu, Jia Ying Sun, Yan Qing Li, Wei Tian, Qian Qian Luo
• Keywords: Honeycomb Weaves, Honeycombed-Core, Three-Dimensional Structure, Weave Repeat Unit

References

[1] Guofa Zou, Guorong Long, Jianping Wan: Fiber Reinforced Plastics/Composites No.6 (2005), p.42(In Chinese)

[2] Liang Wang,Ling Sun: Journal of Wuhan University of Technology Vol.21(2009), p.52(In Chinese)

[3] Ping Zhang, Li Zhou,Tao Qiu: Actc Aeronautica Et Astronautica Sinica Vol.32(1) (2011), p.156(In Chinese)

[4] Jianbing Nie, Xia Reng: Wool Textile Journal Vol.38(11) (2010), p.29(In Chinese)

[5] Chengyan Zhu, Dongyi Tan, Wei Tian: Journal of Textile Research Vol.27(12) (2006), p.9(In Chinese)
