Design of Readout Circuit for Pyroelectric Detector Based on Novel Pyroelectric Materials

Abstract:

Recently, scientists discovered that relaxor-based ferroelectric single crystals, such as (1-x)Pb(Mg_1/3Nb_2/3)O₃ -xPbTiO₃ (PMN-xPT, or PMNT) single crystals, exhibit extra-high pyroelectric responses. They are promising candidates for optical power detectors in broad bandwidth at ultraviolet, visible and infrared wavelength.To fabricate high performance infrared detectors with relaxor-based single crystals, the related readout circuit was investigated to increase signal-to-noise ratio, and 8×1 CMOS readout circuit is fabricated to gain very weak current, which provides a solution for uncooled large focal plane arrays devices based on relaxor-based single crystals.

• Periodical: Advanced Materials Research (Volumes 361-363)
• Pages: 1918-1921
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.361-363.1918
• Online since: October 2011
• Authors: Jiang Wang, Wei Ping Jing, Yan Jin Li
• Keywords: CMOS, PMNT, Pyroelectric Detector, Readout Circuits

References

[1] Y. X. Tang, X. M. Wan, X. M. Pan, D. Lin, and H. S. Luo, J. Appl. Phys. 98, 084104 (2005) .

[2] T. D. Binnie and H. J. Weller, IEEE Trans. Ultrason. Ferroelectr. Freq. Control 47, 1413 (2000).

[3] N. Neumann, H. Sänze, and M. Heinze, TM Tech. Mess. 73, 2 (2006).

[4] J. Fang, Y. J. Li, X. Y. Chen, and J. X. Fang, J. Infrared Millim. Waves 18, 41 (1999).
