Rectifying Behavior of Aligned ZnO Nanorods on Mg0.3Zn0.7O Thin Film Template

Article Preview

Abstract:

Rectifying behavior more than 3 orders of aligned zinc oxide (ZnO) nanorods grown on Mg0.3Zn0.7O thin film template using chemical bath deposition method was observed, giving a barrier height of 0.75 eV, and the ideality factor achieved was almost 6, which was analyzed using thermionic emission theory. Field emission scanning electron microscope (FESEM) images revealed that the grown ZnO was in hexagonal shape, uniformly distributed and in vertically aligned form. The crystallinity of the sample being studied using X-ray diffraction (XRD), where the highest peak was found at (002) phase, confirming that high crytallinity of ZnO was attained. The effect of metal/semiconductor junction between metal and aligned ZnO nanorods was discussed in further details.
