A Novel Speed Sensorless Control of Brushless DC Motor in Position Servo System

Abstract:

Zero crossing points of Back-Electromotive force (EMF) is the most mature and widely used method of the speed sensorless control of brushless DC motor (BLDCM). However, with the poor performance from standstill to low speed, it is not suitable for the position servo system. Therefore, this paper first analyzes several conventional speed sensorless control schemes in the BLDCM, then presents a novel control algorithms for the BLDCM. In the proposed method, the short pulse sensing method for the rotor position in the Start-Up process and self-synchronization with zero cross points of back-EMF are combined together. As a result, the BLDCM used in the position servo system can be easily controlled from zero to high speed, the theoretical analysis is verified by the simulation results based on Matlab, it shows that the proposed algorithms can improve the performances of position servo system compared with the conventional methods.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 4424-4431
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.4424
• Online since: November 2011
• Authors: Chang Chun Chen, Jia Dan Wei, Bo Zhou, Guo Sheng Li
• Keywords: Blushless DC Motor, Control Algorithms, Position Servo System, Sensorless, Start-up Process

References

[1] Shao Jianwen, Nolan D, Teissier M, Swanson D. A novelmicrocontroller-based sensorless brushless DC (BLDC) motor drive for automotive fuel pumps[J]. IEEE Trans. on Industry Applications, 2003, 39(6): 1734-1740.

DOI: 10.1109/tia.2003.818973

[2] Quan Jiang, Ruoyu Huang. A NEW Phase-Delay-Free Method to Detect Back EMF Zero-Crossing Points for Sensorless Control of Spindle Motors. IEEE transactions on magetics, 2005, 41(7): 2287-2294.

DOI: 10.1109/tmag.2005.851841

[3] Johnson J. P, Ehsani M, Guzelgunler Y. Review of sensorless methods for brushless DC[C]. In Proceeding of the IEEE IAS Conference, 1999, 1: 143~150.

DOI: 10.1109/ias.1999.799944

[4] Shenand J X, Tseng K J. Analyses and Compensation of Rotor Position Detection 74 Error in Sensorless PM Brushless DC Motor Drives[J]. IEEE Trans on Energy Conversion, 2003, 18(1): 522-528.

DOI: 10.1109/tec.2002.808339

[5] Ahmcd Rubaai, Rai Kotaru, Masayuki Terashima. A Continually On-line-Trained Neural Network Controller for brushless DC motors Drives[J]. IEEE Trans. on Industry Application. 2000, 36(2): 475-483.

DOI: 10.1109/28.833764

[6] Zou Jibin, Zhang Yu. A Driving Circuit for Sensorless Brushless DC Motor[J]. MICROMOTORS. SERVO TECHNIQUE, 1999, (2).

[7] Krishna R. Lee S. PM Brushless DC Motor Drive with a New Power-converter Topology. IEEE Trans. on Industry Application. 1997, 33 (4): 973-982.

DOI: 10.1109/28.605739

[8] Lin mingyao, Zhang zhiyao, Lin keman. A novel and easy-realizing initial rotor position detection method and speedup algorithm for sensorless BLDC motor drives. Electrical Machines and Systems, 2008. ICEMS 2008. International Conference on Publication Year: 2008 , Page(s): 2860 – 2865.

DOI: 10.1109/icems.2005.202578

[9] Zhang Zhiyao, Lin Mingyao, Zhou Guqing. Anti-Reverse Rotation Startup and Smoothly Switching of Sensorless Brushless DC Motor[J]. Transactions of China Electrotechnical Society, 2009, 24(11): 26-32.

[10] Li Heming. Research on sensorless control of Brushless DC motor[M]. The Master Thesis , Zhejiang University, 2007. 8.

[11] Teng Fulin, Hu Yuwen, Liu Yang, Chu Jianbo. Tracking Performance of Position Servo System Only With Position and Current Loops [J]. Transactions of China Electrotechnical Society, 2009, 24(10): 40-46.
