Droplet Tracking in Double-Electrode GMAW

Abstract:

Controlled metal transfer in gas metal arc welding (GMAW) and its modifications including the double-electrode GMAW implies controllable heat and mass inputs and better assured weld quality. To understand, analyze, and control the metal transfer process, the droplet should be monitored in real time. Due to the fast development and transfer of the droplet, the monitoring speed is a key. A tracking method that takes advantage of results from previous images to speed the processing is advantageous. In this paper, Kalman Filter tracking and Least Square Match tracking algorithms are developed to track a droplet in the innovative double-electrode GMAW after its original position is identified. Experimental results showed that the Kalman Filtering algorithm is not suitable for this application due to the limited life span of each droplet. Instead, the Least Square Match algorithm is effective in tracking a droplet if a universal droplet template can be found and defined. However, there are no universal templates suitable for all the droplets. Hence, a real time template updating and LSM tracking method is proposed to track the droplet effectively. Experimental results verified its tracking accuracy.

You might also be interested in these eBooks

Materials Processing Technology, ICAMMP2011

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 418-420)

Pages:

1180-1183

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.418-420.1180

Citation:

Cite this paper

Online since:

December 2011

Authors:

Zhen Zhou Wang, Yang Yu, Shu Jun Chen, Yu Ming Zhang

Keywords:

Gas Metal Arc Welding, Image Processing, Metal Transfer

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] K.H. Li, J.S. Chen and Y.M. Zhang: Vol. 86, (2007), p. 231s-237s

Google Scholar

[2] N.I. Badler, O. Palmer and R. Bindiganavale:Comm. ACM, Vol. 42, No. 8 (1999), pp.65-73

Google Scholar

[3] Z.Z. Wang and Y.M. Zhang: IEEE Transactions on Automation Science and Engineering, Vol.6, No. 1 ( 2009), pp.181-187

Google Scholar

[4] Z.Z. Wang and Y.M. Zhang: Measurement Science & Technology, Vol.18(2007): 2048-2058

Google Scholar

[5] D. Simon: "Kalman filtering." Embedded system programming, pp.72-79, June (2001)

Google Scholar

[6] G. Welch and G. Bishop. "An Introduction to the Kalman Filtering." Department of Computer Science, University of North Carolina at Chapel Hill, July 24 (2006)

Google Scholar

[7] A. Gruen: South African Journal of Photogrammetry, Remote Sensing and Cartography, Vol.143 (1985), pp.175-187

Google Scholar

[8] N. Apuzzo, R. Plänkers and P. Fua: International Archives of Photogrammetry and Remote Sensing, Vol. 33, Part B5/1, Amsterdam, The Netherlands, (2000) pp.164-171

Google Scholar
