Control System Design of a Novel Fan Shaft Sleeve Automatic Processing Machine

Abstract:

The fan shaft sleeve is a very important part of the fan-related machine and has high demand for precision. At present, due to the lack of machine that exclusively for sleeve processing at home, the sleeve production largely depends on manual labor which yields very low productivity. This paper introduces an automatic machine for fan shaft sleeve processing which introduces the Omron PLC as the hardcore of the control system. The machine proposed also includes a cam splitter. Controlled by motors, clutches and retarders, the splitter provides 6 stations for feeding, drilling, taping, milling, chamfer and discharging. Driven by 3 phases AC motors and air tanks, the machine can mange the fan shaft sleeve processing automatically and achieves high productivity and quality.
