DEM for Modeling Cracks Propagation in Rocks under Uniaxial Compression Tests

Abstract:

The Discrete Element Method (DEM) was used to simulate cracks propagate in rocks subjected to uniaxial compressive stress. A DEM code was developed, and used to simulate the response of the continuum materials to loading. Rock samples with two initial cracks inclined at varying angles were simulated with the DEM code. The results were compared with those obtained from laboratory samples, and it was observed that the two results were consistent. This suggests that the DEM is a robust technique for the visualization of secondary cracks formations and propagations in rocks.

• Periodical: Advanced Materials Research (Volumes 433-440)
• Pages: 4788-4793
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.433-440.4788
• Online since: January 2012
• Authors: Tian Tang Yu, Sheng Xu Xia
• Keywords: Crack Propagation, Discrete Element Method (DEM), Rocks

References

[1] P. Sedsll and D. Polland, Mechanics of discontinous faults, J. Geophys. Res., vol. 85, p.4337– 4350, (1980).

[2] N. Moës, J. Dolbow and T. Belytschko, A finite element method for crack growth without remeshing, Internat. J. Numer. Methods Engrg., vol. 46, p.131–150, (1999).

DOI: 10.1002/(sici)1097-0207(19990910)46:1<131::aid-nme726>3.0.co;2-j

[3] P.A. Cundall and ODL Strack, A discrete numerical model for granular assemblies, Geotechnique, vol. 29, p.47–65, (1979).

DOI: 10.1680/geot.1979.29.1.47

[4] H.P. Zhu, Z.Y. Zhou and R.Y. Yang, Discrete particle simulation of particulate systems: Theoretical developments, Chemical engineering Science, vol. 62, pp.3378-3396, (2007).

DOI: 10.1016/j.ces.2006.12.089

[5] S.A. Magnier and F.V. Donze, Numerical Simulation of Impacts using a Discrete Element Method, Mechanics of Cohesive-Frictional Materials, vol. 3, pp.257-276, (1998).

DOI: 10.1002/(sici)1099-1484(199807)3:3<257::aid-cfm50>3.0.co;2-z

[6] M.S. Hossein and G.N. Erfan, A micromechanical study of rolling and sliding contacts in assemblies of oval granules, Int. J. Numer. Anal. Meth. Geomech., vol. 27, p.403–424, (2003).

DOI: 10.1002/nag.278

[7] F.V. Luis, E.V. Luis and L.G. Sebastian, DEM analysis of the crack propagation in brittle clays under uniaxial compression tests,. International Journal for Numerical and Analytical Methods in Geomechanics, vol. 32, pp.1405-1415, (2008).

DOI: 10.1002/nag.665

[8] R. Hart, P. Cundall and J. Lemos, Formulation of a three-dimensional distinct element model—part II. mechanical calculations for motion and interaction of a system composed of many polyhedral blocks, International Journal of Rock Mechanics and Mining Sciences and Geomechanics Abstracts, vol. 25, p.117–125, (1988).

DOI: 10.1016/0148-9062(88)92294-2

[9] V. Loup, Computer "Experiments" on Classical Fluids. I. Thermodynamical Properties of Lennard-Jones Molecules, Phys. Rev., vol. 159, p.98 –103, (1967).

DOI: 10.1103/physrev.159.98

[10] F.A. Tavarez, Discrete Element Method for Modelling Solid and Particulate Materials [D],. Madison: University of Wisconsin-Madison, (2005).

[11] L. Olovsson, M. Unosson and K. Simonsson, Selective mass scaling for thin walled structures modeled with tri-linear solid elements, Computational Mechanics, vol. 34, pp.134-136, (2004).

DOI: 10.1007/s00466-004-0560-6

[12] P.Z. Pan, W.X. Ding and X.T. Feng, Research on Influence of Pre-existing Crack Geometrical and Material Properties on Crack Propagation in Rocks, Chinese Journal of Rock Mechanics and Engineering, vol. 27, pp.1882-1889, 2008. (in Chinese).
