A Novel Current Reference Calculation Method for Shunt Active Power Filter under Nonideal Mains Voltages

Abstract:

In this paper, the impuissance of traditional ip-iq method in reactive power compensation applications under nonideal mains voltages is illustrated first, and then a novel current reference calculation method for Shunt Active Power Filter (SAPF) based on p-q transformation is proposed. By means of the proposed method, the positive sequence fundamental active current component of the load current can be isolated under distorted and/or unbalanced mains voltages, which makes SAPF be capable of harmonic cancellation and reactive power compensation at the same time under nonideal mains voltages. The effectiveness of the new proposed method is mathematically studied and verified by computer simulation under ideal and nonideal mains voltages.

• Periodical: Advanced Materials Research (Volumes 468-471)
• Pages: 245-251
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.468-471.245
• Online since: February 2012
• Authors: Shou Ming Liu, Hong Wei Shi, Qian Zhang, Zhi Kun Hu
• Keywords: Nonideal Mains Voltages, Positive Sequence Fundamental Active Current, P-Q Transformation, Shunt Active Power Filter

References

[1] S. Jain, P. Agarwal, and H.O. Gupta, "Design simulation and experimental investigations on a shunt active power filter for harmonics and reactive power compensation," Elect. Power Compon. Syst., vol. 32, pp.671-692, Jul. 2003.

DOI: 10.1080/15325000390203674

[2] Zhikun Hu, Zhiwen Chen, Changchun Hua, Jiafeng Ding, "A Novel Digital Control Strategy of Three-phase Shunt Active Power Filter under Nonideal Mains Voltages,". Journal of Central South University of Technology, vol. 9, no. 6, p.2021−2030, June 2011.

DOI: 10.1007/s11771-011-0937-6

[3] Zhikun Hu, Cheng Hu, Jiafeng Ding, Qian Zhang, "On Improved One-cycle Control Scheme for APF Based on Current Feedback," Electric Machines and Control, vol. 15, no.2, pp.20-25, Feb. 2011. (In Chinese)

[4] M. Kale, E. Ozdemir, "An adaptive hysteresis band current controller for shunt active power filter." Electric Power Systems Research, vol. 73, pp.113-119, Feb. 2005.

DOI: 10.1016/j.epsr.2004.06.006

[5] W. Shireen, Li Tao, "A DSP-based active power filter for low voltage distribution systems," Electric Power Systems Research, vol. 78, pp.1561-1567, Sep. 2008.

DOI: 10.1016/j.epsr.2008.01.015

[6] Hao Ma, Zheng Cai, "Comparison of Control strategies for Active Power Filter in Three-Phase Four-Wire Systems." The 30th Annual Conference of the IEEE Industrial Electronics Society, pp.1429-1434,November, 2004.

DOI: 10.1109/iecon.2004.1431788

[7] Jun-min Zhang, Kai-pei Liu, "Harmonic detection for three-phase circuits based on resampling and feedback theory." Proceedings of the 2007 international conference on Wavelet Analysis and Pattern Recognition, pp.29-32,Nov. 2007.

DOI: 10.1109/icwapr.2007.4420630

[8] Shyh-Jier Huang, Jing-chang Wu, and Hurng-Liang Jou, "A study of three-phase active power filters under nonideal mains voltages." Electric Power Systems Research, vol. 49, pp.129-137,Mar.1999.

DOI: 10.1016/s0378-7796(98)00118-7
