Continuous Sheet Metal Forming - A Linearly Incremental Forming Method for Manufacturing 3D Surface Parts

Abstract:

In order to manufacture a three dimensional sheet metal part effectively, a continuous sheet metal forming process (CSMF) based on flexible roll bending has been proposed and developed. This paper mainly focuses on the fundamental aspects of the process, the principle of CSMF is introduced and the method to estimate the downward displacement of upper roll based on the desired curvature of the deformed sheet metal is presented. The variation of the upper rolls downward displacement with the desired bend radius is shown in graphically. The smoothness of the CSMF parts was measured and analyzed. In the results, it is shown that a three-dimensional sheet metal part can be formed without defects and the formed surfaces are in good agreement with the target shapes.

• Periodical: Advanced Materials Research (Volume 486)
• Pages: 334-339
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.486.334
• Online since: March 2012
• Authors: Zhong Yi Cai, Zhi Qing Hu, Ying Wu Lan, Ming Zhe Li
• Keywords: Bending, Continuous Forming, Flexible Roll, Linear Increment, Sheet Metal

References

[1] W.C. Emmens, G. Sebastiani and A.H. van den Boogaard: Journal of Materials Processing Technology, Vol. 210 (2010), p.981.

[2] S. J. Yoon and D.Y. Yang: CIRP Annals-Manufacturing Technology, Vol. 54(2005), p.221.

[3] D.S. Shim, D.Y. Yang, et al.: ICTP 2008 (The 9th International Conference on Technology of Plasticity), (2008), p.2378.

[4] D.S. Shim, D.Y. Yang, et al.: International Journal of Machine Tools & Manufacture, Vol. 50 (2010), p.214.

[5] M.Z. Li, Z.Q. Hu and Z.Y. Cai: Journal of Jilin University (Engineering and Technology Edition), Vol. 37(2007), p.489 (in Chinese).

[6] Z. Y. Cai, M. Z. Li and Y. W. Lan: Journal of Materials Processing Technology, Vol. 212 (2012), p.120.
