Formation Mechanism of Low Angle Boundary of DD6 Single Crystal Superalloy Blades

Abstract:

The specimens were machined from DD6 single crystal superalloy blades with low angle boundary. The misorientation of LAB was measured with EBSD technique in scanning electron microscope. The microstructures of specimens with LAB were examined in optical microscope and scanning electron microscope. The formation mechanism of low angle boundary of DD6 single crystal superalloy blades was investigated. The results showed that he formation of LAB which is caused by the deviating orientation from ideal [001] and the angle between the crystal orientation and shell is crystal selection process acted by dendrite competitive growth rule. Part of dendrites have changed their growth orientation a little to the decreasing [001] orientation departure angle because of solidification condition fluctuating during dendrites branching process. The LAB is the obvious interface between the deforming dendrites and their surrounding dendrites.

• Periodical: Advanced Materials Research (Volumes 535-537)
• Pages: 1019-1022
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.535-537.1019
• Online since: June 2012
• Authors: Zhen Xue Shi, J.R. Li, Shi Zhong Liu, J.Q. Zhao
• Keywords: Blade, DD6, Low Angle Boundary, Single Crystal Superalloy

References

[1] M. Gell, D.N. Duhl, A.F. Giamei, in: Superalloys 1980, edtied by J.K. Tien, S.T. Wlodek, M. Gell, American Society for Metal, Metal Park, 1980, p.205

DOI: 10.7449/1980/superalloys_1980_205_214

[2] D.M. Shah, A. Cetel. in: Superalloys 2000, edtied by T.M. Pollock, R.D. Kissinger, R.R. Bowman, et al. The Minerals, Metals & Materials Society, Warrendale, 2000, p.295

[3] H. Tamaki, A. Yoshimari, A. Okayama, S. Nakamura. in: Superalloys 2000, edtied by T.M. Pollock, R.D. Kissinger, R.R. Bowman, et al. The Minerals, Metals & Materials Society, Warrendale, 2000, p.766

[4] K. Harris, J.B. Wahl. in: Superalloys 2004, edtied by K.A. Green, T.M. Pollock, H. Harada, et al, The Minerals, Metals & Materials Society, Warrendale, 2004, p.45

[5] J.R. Li, Z.G. Zhong, D.Z. Tang, S.Z. Liu, P. Wei, P.Y. Wei, Z.T. Wu, D. Huang, H. Mei. in: Superalloys 2000, edtied by T.M. Pollock, R.D. Kissinger, R.R. Bowman, et al. The Minerals, Metals & Materials Society, Warrendale, 2000, p.777

[6] N. Siredey, M. Boufoussi, S. Denis, J. Lacaze. Journal of Crystal Growth, 30(1993), p.132

[7] A. Wagner, B. A. Shollock, M. Mclean. Materials Science and Engineering A, 374(2004), p.270

[8] K. Dragnevski, A.M. Mullis, D.J. Walker. Acta Mater, 50(2002), p.3743

[9] L.M. Fabietti, R. Trivedi. Journal of Crystal Growth, 173(1997), p.503

[10] F. Liu, X.F. Guo, G.C. Yang. Materials Science and Engineering A, 311 (2001), p.54

[11] N. Stanford, A. Djakovic, B.A. Shollock, M. McLean, N. D'Souza, P.A. Jennings. Scripta Materialia, 2004 (50), p.159
