Research of the Nonlinear 3D Surface NC Machining Technology

Abstract:

Discuss a way of using the CAD/ CAM technology to process nonlinear space surface. By analyzing the processing of nonlinear space surface, the nonlinear space surface machining process plan was determined. The fine model and program was finished by innovative using of combination modeling method in UG. Many key technical problems such as surface finish, work fixture were solved in the process of dealing with CAD/CAM of nonlinear space surface, acceptable product was made on common milling machine by using post-processing NC coding,. The process plan improved machining precision and shortened the production cycle，a good results have been obtained.

• Periodical: Advanced Materials Research (Volumes 538-541)
• Pages: 190-195
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.538-541.190
• Online since: June 2012
• Authors: Hong Jun Liu*, Jie Huang, Shu Ya Zhi
• Keywords: CAD/CAM, Combination Modeling, NC Processing, Nonlinear Space Surface, UG

References

[1] M. Chen, T. Tao: Numerical Control Programming for the List of Fitted Curve, Journal in Chinese of Modular Machine Tool and Automatic Manufacturing Technique 2005(5) PP75-79

[2] X. Jin, X.S. Chen and H. Lei: Integral Impeller CAD/CAM Technology Application Research and Implementation. The Journal in Chinese of Machine Tool and Hydraulics 2007(7) PP53-55

[3] H.J.LIU: Machining Center Technology Application of CAD/CAM. Press in Chinese by Shanghai Science and Technology Press. 2011.8PP102-138

[4] L-Y Zhang, H. Zhang and K-S Wang: Analysis and Research Method for List of Point Curve NC Machining．The Journal in Chinese of Machine Building & Automation 2004(4) PP82-84

[5] J.L.ZHANG, Z.H. LIU and Q-D-YANG：Space Free Surface Five Axis NC Machining. The Journal of Mechanical Design and Manufacturing (in Chinese) 2011 (9) PP129-131

[6] Y.S.GU and J.ZHAO: Space Surface Blade NC Machining. Journal (in Chinese) of Mechanical Design and Manufacturing .2010(5) PP180-182

[7] Y.Q.XIX: Pro/Engineer Application of NC Milling Processing. Journal (in Chinese) of Mechanical Design and Manufacturing 2004 (5) PP92-93

[8] Hasan Oktem, Tuncay Erzurumlu and Mustafa Col: A study of the Taguchi optimization method for surface roughness in finish milling of mold surfaces．Int J Adv Manuf Technol (2006) 28PP 694–700

DOI: 10.1007/s00170-004-2435-6

[9] R-Q.Li, Y-H.Wang, Z-Y.Wu and Z-H.Chen . Automatic generation of an NC machining tool-path for a 3D curve based on polar coordinates. The international Journal of Advanced Manufacturing Technology, 2005, Volume 27, Numbers 11-12, Pages 1119-1123

DOI: 10.1007/s00170-003-2128-6

[10] Xavier Pessoles, Yann Landon and Walter Rubio, Kinematic modelling of a 3-axis NC machine tool in linear and circular interpolation. The International Journal of Advanced Manufacturing Technology, 2010, Volume 47, Numbers 5-8, Pages 639-655

DOI: 10.1007/s00170-009-2236-z
