Dynamic Performance for the Spindle System of the Composite Grinder Based on Transfer Matrix Method

Abstract:

Based on transfer matrix method, the dynamic model is established for the spindle system of a composite grinder, and the modal analysis is carried out. The lower-order modal shape and natural frequency in the determined condition is obtained, and the effects of the support span and the support stiffness on the dynamic characteristics of the spindle system are analyzed. The spindle system’s structure is parameterized by the use of Matlab to improve the efficiency of the modeling and calculation.

• Periodical: Advanced Materials Research (Volumes 538-541)
• Pages: 2477-2480
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.538-541.2477
• Online since: June 2012
• Authors: Ming De Duan, Bo Yin Li, Guo Li Liang, Wu Guo Zhang, Xiao Feng Wang
• Keywords: Dynamic Performance, Modal Analysis, Spindle System, Transfer Matrix Method (TMM)

References

[1] Mu Qian, Shuyun Jiang: J. China Mechanical Engineering. Vol. 16(10)(2005), p.864. (In Chinese).

[2] Haijun Mao: Dynamics Modeling and Optimization for a New Generation of CNC Grinder (Southeast University press, 2001). (In Chinese).

[3] Ce Guo, Qinghong Sun and Shuyun Jiang: J. Mechanical Science and Technology. Vol. 24(9)(2005), p.1009. (In Chinese).

[4] Bangchun Wen, Jialiu Gu and Songbo Xia: Higher rotor dynamics (China Machine press, 2000). (In Chinese).

[5] Jie Meng, Xiaoan Chen: J. Mechanical Science and Technology for Aerospace Engineering. Vol. 27(1)(2008), p.130. (In Chinese).
