Position Sensorless Detection of SRM Based on BP Neural Network

Abstract:

Theory of SRM position detection based on exciting pulse voltage to no conduction phase is analysised, and a combination with BP (back propagation) neural network model to predict SRM rotor position without sensorless is proposed. Training sample and test sample can be obtained by SRM detection system with position sensor, with response current as input, and the rotor position as output, a single input and a single output of BP neural network model is built. Mapping between response current and rotor position are obtained by training BP neural network, and the rotor position prediction is realized, test sample is used to verify the BP neural network model. Simulation results show that this approach improves the detection accuracy compared with the method by injecting exciting pulse voltage.

• Periodical: Advanced Materials Research (Volumes 546-547)
• Pages: 1580-1585
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.546-547.1580
• Online since: July 2012
• Authors: Yong Qin Zhou, Xiao Gang Wu, Teng Wei Yu, Chao Bai, Wen Juan Li
• Keywords: BP Neural Network (BPNN), Sensorless, Switched Reluctance Motor (SRM)

References

[1] Zhou Suying, Lin Hui, in: Sensorless Switched Reluctance Motor Rotor Position Detection Technology, Electrical Drive, Vol. 2(2006), pp.8-9.

[2] Xu Longya, Wang Chuangyang: Accurate Rotor Position Detection and Sensorless Control of SRM for Supre-HighSpeed Operation, IEEE Transactions on Power Electronics, Vol. 17, No. 5 (2005), pp.757-763.

DOI: 10.1109/tpel.2002.802196

[3] H.J. Guo, W.B. Lee, T. Watanabe and O. Ichinokura: An Improved Sensorless Driving Method of Switched Reluctance Motors Using Impressed Voltage Pulse, IEEE, Vol. 3 (2002), P. 977-980.

DOI: 10.1109/pcc.2002.998101

[4] Li Haijun, Hu Qi, Liu Jingjun, in: A New SRM Indirect Position Detection Method, Servo Control, Vol. 3 (2007), pp.39-42.

[5] Wang Xudong, Zhang Yihuang, Wang Xilian, Wang Yan, in: Positions Detection and Forecast of Sensorless Switched Reluctance Motor, Proceedings of the CSEE, Vol. 20, No. 7(2000), pp.5-8.

DOI: 10.1109/icems.2001.970747

[6] Jianbo Cao, Binggang Cao, Wenzhi Chen, Peng Xu and Xiaolan Wu, in: Neural Network Control of Electric Vehicle Based on Position-Sensorless Brushless DC Motor, Proceedings of the 2007 IEEE International Conference on Robotics and Biomimetics. Sanya, China(2007).

DOI: 10.1109/robio.2007.4522457

[7] Yu-Bo Wang, Rui Zhong, Yu-Zhe Xu, Sheng-Li Lu, in: Position sensorless control of SRMs based on novel BP Neural Network, Computer, Mechatronics, Control and Electronic Engineering (CMCE), 2010 International Conference, Vol 3: 304-3(2010).

DOI: 10.1109/cmce.2010.5610333
