Built-In Self-Test Scheme for All-Digital Phase-Locked Loops

Abstract:

This paper presents a low-cost Built-In Self-Test (BIST) scheme, which is based on the principle of parity check code. The proposed circuit is consisted of a XOR network, a frequency decrease module, a BIST controller and a fault detector module. Different from the previous methods of PLL BIST, digital signals from the divide-by-N are grouped as transmission codes, and parity check codes are produced synchronously by the BIST controller. Then the results of parity checking are imported to the fault detector and final test results are generated. Purely digital design flow is adopted and hybrid faults models are used to evaluate the efficiency of the circuit. Experimental results indicates that the proposed method can provide the highest test coverage and lower area overhead, which are 98.3% and 4.2%, respectively.

• Periodical: Advanced Materials Research (Volumes 546-547)
• Pages: 922-927
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.546-547.922
• Online since: July 2012
• Authors: Zhi Kuang Cai, Kai Huang, Jun Yang, Long Xing Shi
• Keywords: ADPLL, BIST, Fault Coverage, Parity Check Code

References

[1] Thomas Olsson and Peter Nilsson, A digitally controlled PLL for SoC applications, IEEE Journal of Solid-State Circuit, vol. 39, p.751–760, May (2004).

DOI: 10.1109/jssc.2004.826333

[2] Ching-Che Chuang and Chen-Yi Lee, An all-digital Phase-Locked Loop for high-speed clock generation, IEEE Journal of Solid-State Circuit, vol. 38, p.347–351, Feb (2003).

DOI: 10.1109/jssc.2002.807398

[3] S. Kim and M. Soma, An all-digital Built-In Self-Test for high-speed Phase-Locked Loop, IEEE Trans. Circuit Syst. II, Analog Digit. Signal Processing, vol. 48, p.141–150, Feb (2001).

DOI: 10.1109/82.917782

[4] Azais F, Bertrand Y, Renovell M, Andre I and Sassan T, An all-digital DFT scheme for testing catastrophic faults in PLLs, IEEE DESIGN & TEST OF COMPUTERS, vol. 20, p.60–67, Jan (2003).

DOI: 10.1109/mdt.2003.1173054

[5] Yu G and Li P, A methodology for systematic built-in self-test of phase-locked loops targeting at parametric failures, IEEE International Test Conference, p.432–441, (2007).

DOI: 10.1109/test.2007.4437606

[6] C. L. Hsu, Y. Lai, and S. W. Wang, Built-in self-test for Phase-Locked Loops, IEEE Trans. Instrum. Meas, vol. 54, p.996–1002, Jul (2005).

DOI: 10.1109/tim.2005.847343

[7] J. Han, D. Song, H. Kim, Y. Y Kim, and S. Kang, An effective Built-in Self-Test for Chargepump PLL, IEICE Trans. Electron, vol. E88-C, p.1731–1733, Aug (2005).

DOI: 10.1093/ietele/e88-c.8.1731

[8] Youbean Kim, Kicheol Kim, Incheol Kim, and Sungho Kang, A new Built-in Self Test scheme for Phase-Locked Loops using internal digital signals, IEICE Trans. Electron, vol. E91-C, p.1713–1716, Oct (2008).

DOI: 10.1093/ietele/e91-c.10.1713

[9] C. L. Hsu and Y. Lai, Low-cost CP-PLL DFT structure implementation for digital testing application, IEEE Trans. Instrum. Meas, vol. 58, p.1897–1906, June (2009).

DOI: 10.1109/tim.2008.2005852

[10] Geisler R, Liobe J, and Margala M, Process and temperature calibration of PLLs with BiST capabilities, IEEE International Symposium on Circuits and Systems, p.3864–3867, (2007).

DOI: 10.1109/iscas.2007.377882

[11] Sunter S and Roy A, Purely digital BIST for any PLL or DLL, IEEE European Test Symposium, p.185–190, (2007).

DOI: 10.1109/ets.2007.35
