Research on Mechanical Performance Analysis and Structural Modification of Longitudinal Thrust Rod

Abstract:

To research the mechanical performance and vibration modes of current longitudinal thrust rod of rear axle, the finite element model of original thrust rod is established and analyzed with NASTRAN codes. The simulation results demonstrate: the maximum stress of original thrust rod of dump truck is in the limit of the yield strength of material, which satisfies with the design requirements; the first step modal frequency of the component under free conditions is greater than upper limits value of the excited frequency of roads, which can evade the resonance excited by irregular roads. But there is structural stress concentration area in the thrust rod, so the structure of thrust rod is modified to ameliorate the stress state of this area. The maximum structural stress is reduced by 35.1% on the basis of reduction by 4.7% in total weight, which indicates the modification improves the mechanical and modal performance greatly. The research above has significant reference values for mechanical performance analysis and lightweight design of complicated automotive components.

• Periodical: Advanced Materials Research (Volume 548)
• Pages: 357-362
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.548.357
• Online since: July 2012
• Authors: Chang Feng Zhou, Gui Qing Zhao, Heng Hai Zhang, Xiao Kang Chen
• Keywords: Finite Element Method (FEM), Modal Analysis, Strength, Thrust Rod

References

[1] Ye Yin, Liu Xintian, Huang Hu. Finite Element Analysis of Rear Sub-frame of Car [J]. JOURNAL OF SHANGHAI UNIVERSITY OF ENGINEERING SCIENCE 2009; 23(4): 308-311 (Chinese Edition).

[2] Chen Jian, Zhou Fugeng, Yuan Chuang. Modal test of a light truck body frame and its FEA analysis [J]. JOURNAL OF HEFEI UNIVERSITY OF TECHNOLOGY 2009; (Sup): 131-134 (Chinese Edition).

[3] Sun Lianke, Tang Bin, XUE Dongxin, Song Xigeng. FEA Optimal Design of Diesel Engine Crankshaft [J]. Tractor & Farm Transporter 2007; 34 (3): 54-56 (Chinese Edition).

[4] Li Zheng. Finite Element Modal Analysis of Gearbox for AUTL Car [J]. Journal of Mechanical Transmission 2008; 32(4): 76-77 (Chinese Edition).

[5] Cauiola P . A modal approach for the evaluation of the response sensitivity of a structural system subjected to non-stationary random process [J]. Computer methods in Applied Mechanics and Engineering 2005; 194(42/44): 4344-4361.

DOI: 10.1016/j.cma.2004.11.006

[6] Yi Dai, Chengwu Duan. Beam element modeling of vehicle body-in-white applying artificial neural network [J]. Applied Mathematical Modelling 2009; 33: 2808-2817.

DOI: 10.1016/j.apm.2008.08.013

[7] Tang YingShi, Duan Xin Lin, Li Kean, Li Ke, Xiao Lijun. Rear Axle Housing Analysis Based on Simulation of Dynamic Vehicle Model [J]. Journal of Hunan University of Science & Technology (Natural Science Edition) 2006; 21(3): 39-42 (Chinese Edition).

[8] Yu Zhisheng. Theory of automobile [M]. 3rd ed. Peking: Mechanical industry press, Jan. 2004 (Chinese Edition).
