Research on Catalytic Combustion of Low Concentration Methane in Combustion Channel of Compact Reformer

Abstract:

The combustion channel of compact methane reformer includes fuel flow duct, porous layer and solid connector. There are heat transport and multi-component species diffusion/convection processes in porous structure. The transfer processes are coupled with methane catalytic combustion, and affect the performance and stability of reformer. A 3D in-house code has been developed to simulate the mass and heat transfer processes involving chemical reactions in the reformer channel in specific condition (mass fraction of CH₄ YCH₄ is less than 1% in the mixture of methane and air). It shows that, catalytic combustion reactions mainly tack place on the porous layer near inlet with a higher temperature area, the biggest heat flux region from the bottom wall is found near the higher temperature area. The reaction rate of methane, temperature of porous layer and heat flux increase with the increase of YCH₄. In general, 0.4% is an adequate value for YCH₄. The research has a benefit meaning to provide a guideline for the improvement and design for compact methane reformer.

• Periodical: Advanced Materials Research (Volumes 550-553)
• Pages: 411-415
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.550-553.411
• Online since: July 2012
• Authors: Chao Yang, Guo Gang Yang, Dan Ting Yue, Xin Rong Lv, Jin Liang Yuan
• Keywords: Combustion Channel, Compact Reformer, Concentration, Methane, Numerical Simulation

References

[1] Yin Yanhong, Li Shaoyu Yang shuting, Research progress in anode materials of SOFC using hydrocarbon as fuel, Battery, 2006, 36(2), pp.155-156

[2] U. Doraswami, P.Shearing, N.Droushiotis, K.Li, N.P. Brandon, G.H. Kelsall. 2011, Modelling the effects of measured anode triple-phase boundary densities on the performance of micro-tubular hollow fiber SOFCs. Solid State Ionics 192, 494-500.

DOI: 10.1016/j.ssi.2009.10.013

[3] Tonlovich A Y，Perry S，Wang Y，et al．Microchannel process technology for compact methane steam reforming．Chemical Engineering Science, 2004, 59 pp.4819-4824.

DOI: 10.1016/j.ces.2004.07.098

[4] Ryi S，Park J，Choi S，et al．Novel micro fuel processor for PEMFCs with heat generation by catalytic combustion[J]．Chemical Engineering Science，2005，113：47-53

DOI: 10.1016/j.cej.2005.08.008

[5] Stefanidis, G. D., Kaisare, N. S., Maestri M., et al.. Methane steam reforming at microscales: operation strategies for variable power output at millisecond contact times. A.I.C.H.E. journal 2009, 55 (1): 180-191

DOI: 10.1002/aic.11672

[6] Ran Jingli, Hu Jianhong, Zhang Li, Characteristics of Generating Hydrogen from Methane-Wet Air Catalytic Reforming Reaction in the Microcombustor, Proceedings of the Chinese Society for Electrical Engineering, 2007, 27(8), pp.42-48.

[7] Robbins F A，Zhu H，Jackson G S．Transient modelling of combined catalytic combustion / CH4 steam reforming[J]．Catalysis Today，2003，83：141-156

DOI: 10.1016/s0920-5861(03)00225-6

[8] Zhang, Li; Yan, Yunfei1; Li, Lixian2; Ran, Jingyu, Numerical investigation of premixed catalytic combustion of methane in micro-combustor, Journal of chemical industry and engineering 2009,60(3), pp.627-633.

[9] Tao Wenquan, Numerical Heat Transfer, Xi'an, Xi'an Jiaotong University Press, (2001)
