The Influence of Cr-Coating on the Thermal Conductivity of Diamond/Cu Composites

Abstract:

Diamond/Cu composites were fabricated by pressure infiltration method with Cr coating onto the diamond particles. The major challenge in the development of these composites is to obtain a well bonded interface between diamond particles and Cu. In this paper, an effective way to apply molten salt method coated chromium on diamond particles was used to solve the interface problem. The results showed that the bonded interface thickness of about 1μm was obtained. The relative density and thermal conductivity of coated composites were 99.5% and 396W/m K respectively, which were remarkably enhanced compared to that of uncoated composites.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 557-559)

Pages:

1654-1658

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.557-559.1654

Citation:

Cite this paper

Online since:

July 2012

Authors:

Qi Ping Kang, Xin Bo He, Shu Bin Ren, Xuan Hui Qu

Keywords:

Coating, Diamond/Cu Composites, Molten Salt Method, Pressure Infiltration Method, Thermal Conductivity (TC)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] K. Yoshida, H. Morigami: J. Microeletron. Reliab. Vol. 44(2004), P. 303

Google Scholar

[2] C. Zweben: J. JOM. Vol.50 (1998), P. 47

Google Scholar

[3] X. Y. Shen, S. B. Ren, X. B. He, M. L. Qin, X. H. Qu: J. Alloys Compd. Vol. 468 (2009), P.158

Google Scholar

[4] S. B. Guo, Q. P. Kang: J. Mater. Mech. Eng. Vol. 34(2010), P. 28

Google Scholar

[5] K. Yoshida, H. Morigami: J. Microelectron. Reliab. Vol. 44 (2004), P. 303

Google Scholar

[6] K. Hanada, K. Matsuzaki, T. Sano: J. Mater. Process. Technol. Vol. 153 (2004), P. 514

Google Scholar

[7] T. Schubert, B. Trindade, T. Weißg¨arber, B. Kieback: J. Mater. Sci. Eng. Vol. 475 (2008), P. 39

Google Scholar

[8] L. Weber, R. Tavangar: J. Scr. Mater. Vol. 57 (2007), P. 988

Google Scholar

[9] S. B. Ren, X. Y. Shen, C. Y. Guo, N. Liu, J. B. Zang, X. B. He, X. H. Qu: J. Comps. Sci. Technol. Vol. 71(2011), P. 1550

Google Scholar

[10] E. A. Ekimov, N. V. Suetin, A. F. Popovich, V. G. Ralchenko: J. Diam. Relat. Mater. Vol. 17 (2008), P. 838

Google Scholar

[11] K. Mizuuchi, K. Inoue, Y. Agari, Y. Morisada, M. Sugioka, M. Tanaka, T. Takeuchi, J. I. Tani, M. Kawahara, Y. Makino: J. Composites: B. Vol.42 (2011), P.825

DOI: 10.1016/j.compositesb.2011.01.012

Google Scholar

[12] Y. Zhang, H. L. Zhang, J. H. Wu, X. T. Wang: J. Scr. Mate. Vol. 65 (2011), P.1097

Google Scholar

[13] T. Schubert, B. Trindade, T. Weißg¨arber, B. Kieback: J. Mater. Sci. Eng. A, Vol. 475 (2008), P. 39

Google Scholar

[14] C.M. Friend: J. Mater. Sci. Vol. 22 (1987), P. 3005

Google Scholar

[15] D. J. Twitchen, C.S. Pickles, S. E. Coe, R.S. Sussmann, C. E. Hall: J. Diam. Relat. Mater. Vol. 10 (2001), P. 731

Google Scholar
