Study on Automobile Body Performance of Honeycomb Sandwich Composite Material

Abstract:

In order to analyze the mechanical properties of Carbon/epoxy facings-Aluminum honeycomb sandwich structure, we simulated panels of different layers and core thickness using ABAQUS finite element analysis program. And three-point bending tests and shear tests were made on the same panels using electronic universal testing machine. In addition, we also made the same three-point bending tests on steel tubes to get a comparison with honeycomb sandwich panels. It could be seen that, the simulated results were basically identified with experimental results. The results indicated that core thickness played an important role in the panels’ bulking modulus, and number of carbon fiber layers decided the shear strength. As a whole, honeycomb sandwich structure was suitable for use in the car body with good mechanical properties under premise of lighter.

• Periodical: Advanced Materials Research (Volume 567)
• Pages: 146-149
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.567.146
• Online since: September 2012
• Authors: Xue Mei Fan, Jian Feng Wang, Cheng Jin Duan, Xiang Xin Xia, Zhao Hui Wang
• Keywords: Automobile Body, Composite Material, Honeycomb Sandwich Structure

References

[1] Q.X. Fan, Honeycomb sandwich composite materials, Journal of Beijing Institute of Light Industry. (1998).

[2] G.P. Zhang, Composite sandwich panels and application, Journal of Fiber Composites. (2000)26-29.

[3] RM. Measure，Advances toward fiber optic based smart structures, Journal of Optic Engineering. 31(1992)34-47.

[4] Z. Shi, Composite sandwich structures in automotive applications, Journal of Fiber Reinforced Plastics/Composites. 4(1997).

[5] B. Chen, Application and trend on synthetic material using in automobile, Journal of Fiber Composites. 3(2002).

[6] X.D. Chen, The bending stiffness test of ultra-thin aluminum honeycomb sandwich structure, Journal of Aerospace Technology. 4(1995).
