Sphere-Based Geometrical Calibration Method for Structured Light Surface Measurement Systems

Abstract:

This paper proposes a sphere-based calibration method for the structured light system with unconstrained one projector & one camera, regardless of pattern codification. A 1-pose example of such a method is also proposed and tested. In comparison with a traditional plane translation method of 15 poses, we note an increase in the consistency of more than 10% while the calibration time shrinks to 6% and the calibration accessory is reduced to the size of a flash-light. This method suits well for applications where mobility, speed and ease-of-use are important criteria.

You might also be interested in these eBooks

Opto-Electronics Engineering and Materials Research

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 571)

Pages:

433-438

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.571.433

Citation:

Cite this paper

Online since:

September 2012

Authors:

Jules Douet, Jing Xu, Ken Chen

Keywords:

Calibration, One-Shot, Sphere, Structured Light, Surface Measurement

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] P. J. Tavares and M. A. Vaz, Linear calibration procedure for the phase-to-height relationship in phase measurement profilometry, Opt. Commun, vol. 274, no. 2, p.307–314, June (2007).

DOI: 10.1016/j.optcom.2007.02.038

Google Scholar

[2] M. H. Du, Z. Wang, Three-dimensional shape measurement with an arbitrarily arranged fringe projection profilometry system, Opt. Lett. vol. 32, no. 16, p.2438–2440, August (2007).

DOI: 10.1364/ol.32.002438

Google Scholar

[3] R. Anchini, G. Di Leo, C. Liguori, A. Paolillo, A new calibration procedure for 3-D shape measurement system based on phase-shifting projected fringe profilometry, IEEE Trans. Instrumentation and Measurement, vol. 58, no. 5, p.1291–1298, May (2009).

DOI: 10.1109/tim.2009.2012952

Google Scholar

[4] J. Gühring, Dense 3-d surface acquisition by structured light using of-the-shelf components, Videometrics Opt. Meth. 3D Shape Meas. Vol. 4309, p.220–231, (2001).

Google Scholar
