A Three-Channels WDM Based on Multimode Interference Photonic Crystal

Abstract:

A photonic crystal waveguide coupled structure can be constructed by putting three photonic crystal waveguides in parallel and adjacent form. Study the coupling of the approximate solution interference acts and the self-image phenomenon of this multi-mode waveguide system based on the guided mode propagation analysis method, a three-channels multimode interference wavelength division multiplexing is designed. The presented device not only has a high transmission rate, but also has the advantages of multiple wavelength selection and may have potential and practical applications in the field of photonic integrated circuits in future.

• Periodical: Advanced Materials Research (Volume 571)
• Pages: 445-449
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.571.445
• Online since: September 2012
• Authors: Jia Han Yan
• Keywords: Coupling, Multimode-Interference (MMI), Photonic Crystal Waveguide, Wavelength Division Multiplexing

References

[1] John S.: Strong localization of photons in certain disordered dielectric superlattices. Phys. Rev. Lett., Vol. 58 (1987), pp.2486-2489.

DOI: 10.1103/physrevlett.58.2486

[2] Zhang Yao, Li Zhangjian and Li Baojun: Multimode interference effect and self-imaging principle in two-dimensional silicon photonic crystal waveguides for terahertz waves. Optics Express, Vol. 14(2006), pp.2679-2689.

DOI: 10.1364/oe.14.002679

[3] Guo Hao, Wu Ping, Yu Tian-Bao, Liao Qing-hua, Liu Nian-hua and Huang Yong-zhen: Design of novel polarization beam splitter in two-dimensional photonic crystal. Acta Physica Sinica, Vol. 59(2010), pp.5547-5551.

DOI: 10.7498/aps.59.5547

[4] Manzacca G, Paciotti D, Marchese A and Cincotti G: 2D photonic crystal cavity-based WDM multiplexer. Photonics and Nanostructures-Fundamentals and Applications, Vol. 5(2007), pp.164-170.

DOI: 10.1016/j.photonics.2007.03.003

[5] Liu T, Zakrian A R, Fallahi M, Moloney J V and Mansuripur M: Design of a compact photonic-crystal-based polarizing beam splitter. IEEE Photon. Technol. Lett, Vol. 17(2005), pp.1435-1437.

DOI: 10.1109/lpt.2005.848278

[6] Drysdale T D, Blaikie R J and Cumming D R S: Calculated and measured transmittance of a tunable metallic photonic crystal filter for terahertz frequencies. Appl. Phys. Lett., Vol. 83(2003), p.5362~5364.

DOI: 10.1063/1.1636822

[7] Chen C C, Chen C Y and Wang W K: Photonic crystal directional couplers formed by In AlGaAs nano-rods. Opt. Express, Vol. 13(2005), pp.38-43.

DOI: 10.1364/opex.13.000038

[8] Yang Chun-yun, Xu Xu-ming, Ye Tao and Miao Lu-ping: The modulation of a novel photonic crystal ring resonator filter. Acta Physica Sinica, Vol. 60(2011), pp.017807-5.

DOI: 10.7498/aps.60.017807

[9] Barwicz T, Popovic M, Rakich P, Watts M, Haus H, Ippen E and Smith H: Microring-resonator based add-drop filters in SiN. fabrication and analysis, Vol. 12(2004), pp.1437-1442.

DOI: 10.1364/opex.12.001437

[10] B. Yu, M. H. Wang, X. Q. Jiang and J.Y. Yang: Coupling characteristics of electromagnetic wave in parallel three photonic crystal waveguides and its applications. Acta Phys. Sinica, Vol. 55(2006), pp.1851-1851.
