Optical-Mode Study of Galium Nitrate Based Laser Diodes

Abstract:

This paper focuses on the optical mode analysis of laser diodes to improve light emission. Under the mode analysis, we compare the optical confinement factor (OCF) percentage of the emitting light from the LDs. There are two structures which we analyze: a basic GaN waveguide structure and an InGaN waveguide structure. The second structure has additional InGaN waveguides and is analyzed under two additional design variations: the concentration of Indium and the thickness of the top waveguide layer. The results of this study indicate introducing InGaN waveguide layers correlates with lower order modes (zero and first order) and increase the OCF values. The top InGaN waveguide layer, which has a higher concentration of Indium, appears to increase the OCF. However, the increased thickness of the InGaN layer causes the lower modes’ OFC to decrease. Over all, in the best case, InGaN LD has an OCF of 1.8896%, which is about a 312% improvement compared to that of GaN LD ( OCF=0.4535%).

• Periodical: Advanced Materials Research (Volume 571)
• Pages: 476-481
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.571.476
• Online since: September 2012
• Authors: Douglas Alan Cattarusa, Xiao Min Jin, Xing Xing Fu, Xiang Ning Kang, Bei Zhang, Guo Yi Zhang
• Keywords: Laser Diode, OCF, Waveguide

References

[1] D.R. Jones, P. Rees, and I. Pierce: Optimisation of InGaN narrow stripe self-pulsating laser diodes, Conference on Laser and Electro-Optics Europe (2000), p.1.

DOI: 10.1109/cleoe.2000.910115

[2] S.P. Denbaars: Gallium-nitride-based materials for blue ultraviolet optoelectronics devices, Proceeding of the IEEE, vol. 85 (1997), p.1740.

DOI: 10.1109/5.649651

[3] M.A. Khan, G. Simin, S.G. Pytel, A. Monti, E. Santi, and J.L. Hudgins: New developments in gallium nitride and the impact on power electronics, Postsecondary Electronic Standards Council (2005), p.15.

DOI: 10.1109/pesc.2005.1581596

[4] G. Guekos and M. Strutt: Laser-light noise and current noise of GaAs CW laser diodes, IEEE Journal of Quantum Electronics Vol. 6 (1970), p.423.

DOI: 10.1109/jqe.1970.1076500

[5] X. Jin, B. Zhang, L. Chen, T. Dai, and G. Zhang: Optimization of gallium nitride-based laser diode through transverse modes analysis, in Chinese Optics Letters Vol. 5 (2007), p.588.

[6] X. Jin, B. Zhang, T. Dai , and G. Zhang: Effects of transverse mode coupling and optical confinement factor on gallium-nitride based laser diode, in Chinese Physics B Vol. 17 (2008), p.1274.

DOI: 10.1088/1674-1056/17/4/021

[7] M. Boroditsky and E. Yablonovitch: Light extraction efficiency fromlight-emitting diodes, Proc. SPIE Vol. 3002(1997), p.119.

[8] P.G. Eliseev, G.A. Smolyakov, and M. Osinski: Ghost Modes and Resonant Effects in AlGaN—InGaN—GaN Lasers, IEEE Journal of Selected Topics in Quantum Electronics Vol. 5(1999), p.771.

DOI: 10.1109/2944.788450

[9] J. Liu, Y. Zhang, Z. Lochner, S. Kim, J. Ryou, S. Shen, R. Dupuis, Q. Wei, K. Sun, A. Fischer, and F. Ponce: Performance improvement of InGaN-based laser diodes by epitazial layer structure design, Proc. SPIE, Vol. 7602, 760219(2010).

DOI: 10.1117/12.842334

[10] Rsoft design Inc., Application notes of LaserMOD, (2006).
