Based on Pro/Toolkit Parametric Design of the Longitudinal Roadheader Cutting Head

Abstract:

Through to the analysis and design of cutting head, three-dimensional molding software Pro/E as the foundation, and vc++6.0 as a Second development tools, as well as achieved automatic update and assembly of the parts of cutting head, and shorten the design cycle.The environment of achieving cutting head in parametric CAD,the coal industry special equipment for coal mine normalized components parametric design has the great significance,for parametric designed of other products, provided valuable experience, great value.

• Periodical: Advanced Materials Research (Volume 619)
• Pages: 195-198
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.619.195
• Online since: December 2012
• Authors: Li Juan Zhao, Zheng Jun Wu, Zhen Tian
• Keywords: Parametric Design, Pro/Toolkit, Second Development, Virtual Assembly

References

[1] Li Shi-guo. Program Design of Pro/TOOLKIT[M]. Beijing: Mechanical Industry Press, (2003).

[2] Chen Fang, Fu Jing. Research on the Secondary Development of Pro/E Based on Pro/ Toolkit[J]. Journal of He'nan Mechanical and Electrical Engineering College, 2009, 17(5): 17-19.

[3] Yang Guo-dong, Gao Cheng-xing, Zhou Kun-ming. Research of Roadheader Longitudinal Design Parameters of Cutting Head[J]. Coal Mine Machinery, 2011, 32(6): 46-48.

[4] Coal Industry Special Equipment Standardization Technical Committee. MT/T246-2006 cutting teeth of mining machinery[S]. Beijing: Coal industry press, (2006).

[5] Coal Industry Special Equipment Standardization Technical Committee. MT/T246-2006 tooth holder of mining machinery[S]. Beijing: Coal industry press, (2006).
