The Vibration of Spur Gear Pair with Strong Nonlinear Suspension

Abstract:

In this paper, the pure rotational dynamic model of one stage gear pair system is developed and the nonlinear factors, such as strong nonlinear suspension, time-varying mesh stiffness, piece-wise backlash and internal error excitation, are included in our model. The relative mesh displacement is employed to convert the semi-define system with rigid displacement model into a define one. Such qualitative and quantitative methods as the bifurcation diagram, Lyapunov exponents, Poincaré section, phase trajectory, power spectrum and time history curve are utilized in present research to illustrate the nonlinear dynamic behavior of the system. The sub-harmonic response, chaotic response and the route to chaos of the system are revealed based on one applicable numerical integration method.

• Periodical: Advanced Materials Research (Volume 629)
• Pages: 501-505
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.629.501
• Online since: December 2012
• Authors: Xiao Sun Wang, Shi Jing Wu, Ji Cai Hu, Ze Ming Peng
• Keywords: Bifurcation, Chaos, Nonlinear Suspension, Spur Gear Pair

References

[1] H.N. Ozguven, Mathematical models used in gear dynamics, Journal of Sound and Vibration, 121(1988): 383–411.

[2] A. Kahraman, R. Singh, Non-linear dynamics of a spur gear pair, Journal of Sound and Vibration, 142(1990): 49–75.

DOI: 10.1016/0022-460x(90)90582-k

[3] A. Raghothama, S. Narayanan, Bifurcation and chaos in geared rotor bearing system by incremental harmonic balance method[J], Journal of Sound and Vibration, 226(1999): 469-492.

DOI: 10.1006/jsvi.1999.2264

[4] LIU Mengjun, SHEN Yunwen, DONG Haijun. Research on Numerical Characters of the Attractors in a Nonlinear Gear System, Journal of Mechanical Engineering (in chinese), 39(2003): 111-116.

DOI: 10.3901/jme.2003.10.111

[5] R.G. Parker, S.M. Vijayakar, T. Imajo, Non-linear dynamic response of a spur gear pair: modeling and experimental comparisons, Journal of Sound and Vibration, 237(2000): 435–455.

DOI: 10.1006/jsvi.2000.3067

[6] A. Al-shyyab, A. Kahraman, Non-linear dynamic analysis of a multi-mesh gear train using multi-term harmonic balance method: sub-harmonic motions, Journal of Sound and Vibration, 279(2005): 417–451.

DOI: 10.1016/j.jsv.2003.11.029

[7] Cai-Wan, Chang-Jian, Strong nonlinearity analysis for gear-bearing system under nonlinear suspension—bifurcation and chaos, Nonlinear Analysis: Real World Applications, 11(2010): 1760-1774.

DOI: 10.1016/j.nonrwa.2009.03.027

[8] Cai-Wan, Chang-Jian, Bifurcation and chaos analysis of spur gear pair with and without nonlinear suspension, Nonlinear Analysis: Real World Applications, 12(2011): 979–989.

DOI: 10.1016/j.nonrwa.2010.08.021

[9] Theodossiades S, Natsiavas S. Non-linear dynamics of gear-pair systems with periodic stiffness and backlash., Journal of Sound and Vibration, 229(2000): 287–310.

DOI: 10.1006/jsvi.1999.2490
