Keyboard Design for UAV Ground Station Based on VC++ Multi-Thread Technology

Abstract:

For the flight velocity of some UAV is high and the practice operation is much complex, the ground station keyboard based on multi-thread technology is designed. Also the keyboard is on the base of MSComm control in VC++ 6.0. There are two threads in this keyboard. According to the Serial Communication Protocols defined original the main thread accepts and transfers ground station command and GPS information. At the same time, the other thread scans matrix keyboard from which the UAV sends remote control command. The experiments testify that the keyboard can control UAV smoothly; meanwhile it is easy to operate for its simple configuration.

• Periodical: Advanced Materials Research (Volume 630)
• Pages: 335-338
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.630.335
• Online since: December 2012
• Authors: Dong Li Yuan, Huan Li, Ao Xi, Zheng Ming Zhang, Jing Wei
• Keywords: Multi-Thread Technology, Serial Communication, Unmanned Aerial Vehicle (UAV), Virtual Serial Ports

References

[1] Sun Xin, Yuan Ping, VC++ Explain in depth, Publishing House of Electronics Industry, Nov. (2007).

[2] Gong Jianwei, Xiong Guangming ed, Visual C++/Turbo C Serial port communication programming practice, Publishing House of Electronics Industry, Dec. (2004).

[3] Wu Yiming, Ground comprehensive test system research and implementation of a certain type UAV, Master thesis f Northwestern Polytechnical University, (2006).

[4] Zhou Juntao. The design and realization of UAVs' Automated Integrated Test system based on Virtual instrument, Master thesis of Northwestern Polytechnical University, (2007).

[5] Ning Jinxing, Lu Jingchao, Yan Jianguo. Design of Software for UAV Flight Control Ground Station Based on VC++, Computer Measurement & Control, (2009).
