Simulation and Optimization Research of Multi-Stud Tensioning Machine Controlled by Servo Valve

Abstract:

In this paper, we base on the simulation analysis of the electro-hydraulic servo system about dual hydraulic cylinders parallel driving Multi-Stud Tensioning Machine, focus on the dynamic characteristics of a single hydraulic cylinder (asymmetric hydraulic cylinder), make use of Matlab Simulink module to carry on to imitate, and design a PID controller to correct the system. The results of simulation prove correctness of the system mathematic model, and the stability of the system is obviously improved.

• Periodical: Advanced Materials Research (Volume 664)
• Pages: 871-877
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.664.871
• Online since: February 2013
• Authors: Xiao Dong Tan, Wei Ji, Zhi Bo Luan
• Keywords: Asymmetric Hydraulic Cylinder, MATLAB/SIMULINK, Multi-Stud Tensioning Machine, PID Control

References

[1] Fenghe Wu, Rongjuan Yuan: the hydraulic tensile preload of large diameter bolts. Heavy machinery, (2001).

[2] Junjie Liu, Zhengming Zhang, et: Multi-Stud Tensioning Machine of 10 MW High temperature air-conditioning reactor pressure vessel. Nuclear Power Engineering, (2000).

[3] Yejian Zhang, Hongren Li: the study of hydraulic cylinder chamber pressure characteristics about asymmetrical cylinder system. Machine and hydraulic. (2000).

[4] Hongli Wang, Ding Fan, et: Research on Dynamic Characteristics of Asymmetric Cylinder Controlled by Symmetric Four- way Valve. China Mechanical Engineering, (2004).

[5] Zhili Sun, Xingju Leng, et: Mechanical design. Northeastern University Press, (2000).

[6] Jorg Hohmann, Frank Hohmann, et: Hydraulic Threaded Bolt Clamping Device And Method For Tightening Large Screws By Means Of Said Hydraulic Threaded Bolt Clamping Device United States Patent, US 7, 469, 592 B2, DEC. 30, (2008).
