Micro-Structure and Magnetic Properties of Hexagonal M-Type Ferrite Thick Films Prepared by Tape Casting

Abstract:

The M-type hexagonal ferrite thick films are prepared by tape casting . The morphology is investigated by scanning electron microscope (SEM), the phase composition is characterized by X-ray diffraction (XRD) and the magnetic properties are characterized by vibrating sample magnetometer (VSM). The result shows that thick film by tape casting has high remanence as 26.607emu/g, high magnetization as 55.236emu/g, high coercivity as 2323.8Oe, and high squareness ratio and a good morphology which is suitable for small and light-weight microwave and millimeter-wave devices .

• Periodical: Advanced Materials Research (Volume 668)
• Pages: 753-756
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.668.753
• Online since: March 2013
• Authors: Fu Chen, Zhong Yan Chen, Yuan Zhou, Ze Kun Feng
• Keywords: Magnetic Anisotropy, Micro Wave Devices, Millimeter Wave Devices, Tape Casting, Thick Film

References

[1] B. Pawlowski, S. Schwarzer, A. Rahming, J. Topfer. NdFeB thick films prepared by tape casting. Journal of Magnetism and Magnetic Materials. 265(2003): 337-344.

DOI: 10.1016/s0304-8853(03)00285-3

[2] Jaejin Lee, Yang-Ki Hong, Woncheol Lee, Gavin S. Abo, Jihoon Park et al. Soft M-type hexaferrite for very high frequency miniature antenna applications. Journal of Applied Physics 111, 07A520(2012).

DOI: 10.1063/1.3679468

[3] CHEN Zhong-yan, FENG Ze-kun, XIONG Xuan. Study on Barium Ferrite Thick Films by Screen Printing and Magnetic Orientation. Journal of Magentic Materials and Devices. 2010, 41(2): 22-24, 45.

[4] Z.C. Yuan, A.J. Williams, T.C. Shields, S. Blackburn, C.B. Ponton, J.S. Abell, I.R. Harris. The production of Srhexagerrite thick films by screen printing. Journal of Magnetism and Magnetic Materials 247(2002): 257-269.

DOI: 10.1016/s0304-8853(02)00182-8

[5] Yajie Chen, Tomokazu Sakai, Taiyang Chen, Soack D. Yoon, Carmine Vittoria, and Vincent G. Harris. Screen printed thick self-biased, low-loss, barlumhexaferrite films by hot-press sintering. Journal of Applied Physics 100. 043907(2006).

DOI: 10.1063/1.2221527

[6] Anton Geiler, Andrew Daigle, Jianwei Wang, Yajie Chen, Carmine Vittoria, Vince Harris. Consequences of magnetic anisotropy in realizing practical microwavehexaferrite devices. Journal of magnetism and magnetic materials , 2012, 28.

DOI: 10.1016/j.jmmm.2012.02.050

[7] Vincent G. Harris, Fellow, IEEE. Modern Microwave Ferrite. IEEE Transactions on Magnetics. 2012, 48(3) : 1075-1104.

[8] WANG Ke, QIU Tai. Research progress on tape casting forming process of ferrite substrate. Electronic components and Materials, 2011, 30(1): 79-82.

[9] Hsing-I Hsiang, Chih-Cheng Chen, Jaw-Yue Tsai. Dispersion of nonaqueous ferrite powders with titanate coupling agent and poly(vinyl butyral). Applied Surface Science , 2005, 30(5): 252-259.

DOI: 10.1016/j.apsusc.2004.10.048

[10] HUANG Zhao-lin, ZHANG Wan-li, PENG Bin. Influence of organic vehicles on microstructure of thick barium hexaferrite films. Journal of functional materials and devices. 2011, 17(1): 69-73.
