Optimization and Flow Analysis of Ducted Tidal Stream Turbine

Abstract:

Efficiency of the tidal stream turbine with thin-wall axisymmetric ducts was numerically simulated. The ducts design parameters of diffuser curves, expansion ratio and duct length were simply optimized. The results showed that the duct of second order diffuser curve, expansion ratio of 2.25 and a length-diameter ratio of 1.2 has the best performance. By comparison of different ducts flow, it revealed that flow separation at the duct outlet and the ejection influenced ducted turbine efficiency. The separation caused blockage and flow rate decreasing, and so performance deteriorated. The ejection caused lower pressure at the outlet of the duct, which allowed higher pressure drop through turbine impeller, and so improved turbine efficiency.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 694-697)

Pages:

683-688

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.694-697.683

Citation:

Cite this paper

Online since:

May 2013

Authors:

Jun Wei Zhou, Da Zheng Wang, Ya Nan Li

Keywords:

Ducted Turbine, Flow Analysis, Numerical Simulation, Parameter Optimization

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] FRAENKEL P L. Power from marine currents [J]. Proceedings of the Institution of Mechanical Engineers, Part A: Journal of Power and Energy, 2002, 26(1)：1-14.

Google Scholar

[2] BATTENA W M J, BAHAJA A S, MOLLANDB A F, et al. Hydrodynamics of marine current turbines [J]. Renewable Energy, 2006, 31(2)：249-256.

Google Scholar

[3] Junwei Zhou, Dazheng Wang, Bin Guo , et al. Design and optimization of bidirectional tidal turbine [A]. Proceedings of the Seventh International Workshop on Ship Hydrodynamics[C]. Shanghai：Shanghai JiaoTong University, 2011.

Google Scholar

[4] M O L HANSEN, N N SØRENSEN, R G J FLAY. Effect of Placing a Diffuser around a Wind Turbine [J]. Wind Energy, 2000, 3:207–213.

DOI: 10.1002/we.37

Google Scholar

[5] YUJI OHYA, TAKASHI KARASUDANI, AKIRA SAKURAI, et al. Development of a shrouded wind turbine with a flanged diffuser [J]. Journal of Wind Engineering, 2008, 96：524-539.

DOI: 10.1016/j.jweia.2008.01.006

Google Scholar

[6] Gilbert B L, Foreman K M. Experiments with a diffuser-Augmented model wind turbine [J]. Journal of Energy Resources Technology, 1983, 105:46-53.

DOI: 10.1115/1.3230875

Google Scholar

[7] IBRAHIM AL-BAHADLY, A F T PETERSEN. A Ducted Horizontal Wind Turbine for Efficient Generation[A]. Wind Turbines, http://www.intechopen.com/books/wind-turbines/a-ducted- horizontal-wind-turbine-for-efficient-generation, INTECH, 2011.

DOI: 10.5772/15050

Google Scholar

[8] Junwei Zhou, Weichao Shi and Dazheng Wang. The analysis of duct tidal stream turbine passage flow efficiency. Proceedings of the first China Marine Renewable Energy[C]. In Beijing, 2012.

Google Scholar
