The Electromechanical Transient Simulation Study of the Short Current Current-Limiter

Abstract:

With the expansion of the grid scale, the level of short-circuit current is significantly increased, we propose more stringent requirements to the grid. Limiting the short-circuit current is a problem to be solved.This paper used PSS/E to build the electromechanical transient simulation models of the SCCL device. We tested and checked the models by the system of IEEE 9 nodes 3 machines and concluded: In the current limiter parameters, the larger the inductor is,the better the effect of limiting current is. In the same resistance situation,the larger the inductance is, the better the effect of limiting current is, the smaller the short-circuit current value is.

• Periodical: Advanced Materials Research (Volumes 753-755)
• Pages: 2557-2565
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.753-755.2557
• Online since: August 2013
• Authors: Jian Qiao, Xiao Bo Liu, Jia Yu Wei
• Keywords: Electromechanical Transient Simulation, Fault Current Limiter Device, Grid, Short-Circuit Current

References

[1] P．Behrens，A．Cieleit'E．K．Stachorra．Fault current limiters as power quality device in distribution networks-tcclmique，experience，trends.

[2] Working Group A3. 23. Application and Feasibility of Fault Current Limiters in Power Systems. Paris : GIGRE，(2012).

[3] Thuries E，Pham V D, et al. Towards the superconducting fault current limiter. IEEE Trans. on Power Delivery. 1991，6（2）：801～808.

DOI: 10.1109/61.131138

[4] Czucha J, Lipski T, Zyborski J. Hybrid current limiting interrupting device for 3-phase AC application. In：IEE Trends in Distribution Switchgear, No. 459， 1998: 161～166.

DOI: 10.1049/cp:19980759

[5] Kado H. Performance of high-Tc superconductivity fault current limiter. IEEE Trans. on Applied Superconductivity, 1995，5（2）：993～996.

DOI: 10.1109/77.614672

[6] Keilin V，Kovalev I，et al. Model of HTS three-phases fault current limiter. IEEE Trans. on Applied Superconductivity，2000，10（1）：836～839.

DOI: 10.1109/77.828361

[7] Shi Jing，Zou Jiyan，He Junjia. Triggered vacuum switch-based fault current limiter. IEEE Power Engineering Review，2001，21（1）：51～53.

DOI: 10.1109/39.893342

[8] CIGRE WG A3. 23. Application and Feasibility of Fault Current Limiters in Power Systems. (2008).

[9] IEEE PC37. 302. Guide for Fault Current Limiter Testing（not completed）. (2010).

[10] CIGRE WG D1. 38. Emerging Test Techniques Common to High Temperature Superconducting (HTS) Power Applications. (2011).
