Numerical Study on Repairing Mold Punch of Wear Failure by Manual Arc Welding

Abstract:

In order to achieve a more intensive understanding of the plate welding mechanism of the punch repairing process, a numerical simulation has been carried out by using the finite element method. According to the special requirement of the punch, which had been the wear failure, the surface welding surfacing have been taken into account in the finite element model. The results of the finite element simulation are in proper agreement with the experimental findings. The distributions of the Von Mises Stress of the workpiece have been computed for discussion. It has been realized that good results could be got by finite element computation.

• Periodical: Advanced Materials Research (Volumes 753-755)
• Pages: 417-420
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.753-755.417
• Online since: August 2013
• Authors: Yong Fu Yuan, Cun Ping Liu
• Keywords: Finite Element Method (FEM), Manual Arc Welding, Punch, Wear Failure

References

[1] Kuldeep Agarwal, Rajiv Shivpuri, Justin Vincent, Edward Rolinski, Gary Sharp. DC pulsed plasma deposition of nanocomposite coatings for improved tribology of gray cast iron stamping dies. Journal of Materials Processing Technology, 213 (2013).

DOI: 10.1016/j.jmatprotec.2013.01.002

[2] Dhouha Mellouli, Nader Haddar, Alain Köster, Hassine Ferid Ayedi. Thermal fatigue failure of brass die-casting dies. Engineering Failure Analysis, 20 (2012) 137-146.

DOI: 10.1016/j.engfailanal.2011.11.006

[3] T. Altan, B.W. Lilly, J.P. Kruth, W. König, H.K. Tönshoff, C.A. van Luttervelt, A.B. Khairy. Advanced Techniques for Die and Mold Manufacturing. CIRP Annals- Manufacturing Technology, 42 (1993) 707-716.

DOI: 10.1016/s0007-8506(07)62533-5

[4] E. Capello, D. Colombo, B. Previtali. Repairing of sintered tools using laser cladding by wire. Journal of Materials Processing Technology, 164–165(2005) 990-1000.

DOI: 10.1016/j.jmatprotec.2005.02.075

[5] T. Branza, A. Duchosal, G. Fras, F. Deschaux-Beaume, P. Lours. Experimental and numerical investigation of the weld repair of superplastic forming dies. Journal of Materials Processing Technology, 155–156(2004) 1673-1680.

DOI: 10.1016/j.jmatprotec.2004.04.388

[6] L.P. Borrego, J.T.B. Pires, J.M. Costa, J.M. Ferreira. Mould steels repaired by laser welding. Engineering Failure Analysis, 16 (2009) 596-607.

DOI: 10.1016/j.engfailanal.2008.02.010

[7] Wang Jianhua, Qi Xinhai, Zhong Xiaomin. 3-D Simulation of Transient Welding Temperature Fields by FEM. Journal of Shanghai Jiaotong University. 30(1996) 120-125.

[8] Chen Chu Wang Jianhua Yang Hongqing. Analysis and Calculation of Non-linear Welding Heat Conduction by Finite Element Method. Transactions of The China Welding Institution. 4 (1983) 139-146.
