Study on a Craft Simulation Technology for the MEMS Thermal Element

Abstract:

On the basis of the craft manufacturing and designing about micro fluidic gyroscope, according to analyze the craft information and studying on the process simulation technology about the MEMS thermal components. Established a basic model of t the craft structure about the MEMS thermal components, based on this model, the L-Edit editor to edit creating a complete mask layout structure; studying a simulation method of craft process, the use of the technological editor which development based on the TCL/TK language to draw out the craft process document, then reconstructed the layout structure based the craft process in a 3D platform. It could be used to detect the rationality of the process program technology.

• Periodical: Advanced Materials Research (Volumes 756-759)
• Pages: 4217-4220
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.756-759.4217
• Online since: September 2013
• Authors: Chuan Zhi Mei, Lin Hua Piao, Bao Li Zhang
• Keywords: Layout Structure, MEMS Craft, Process Document, Thermal Components

References

[1] Yao Yahong. The micro mechanical gyro micro structure design and manufacture technology research of [D]. Beijing: Tsinghua University Department of precision instruments. (1998).

[2] Li Xingang, Yuan Jianping . Progress in the development of [J], micro mechanical gyro mechanics, 2003, 33 ( 3 ): pp.289-301.

[3] Fang Zhihua MEMS layout on 3D reconstruction technology of [D]. Xi'an: Northwestern Polytechnical University micro nano laboratory. (2004).

[4] Sun Run et al. TANNER IC design [M]. Beijing: Beijing Hope Electronic Press, 2002: 12.

[5] Liu Dan, Li Xiaoying, Chang Honglong. Realization and [J]. machine design and manufacture of an editor for MEMS process, 2007, 2: pp.144-147.

[6] Xie Jianbin, Yuan Weizheng, often Honglong, Xu Jinghui. A MEMS CAD system level design level layout generation technology of [J]. science technology and engineering, 2006, 6 ( 13 ): 1955-(1958).
