Study on Fluidic Gyroscope Linearity Compensation Method

Abstract:

Based on the linearity of the MEMS thermal element fluidic gyroscope compensation. By analyzing the results of the linear characteristic of the fluidic gyroscope sensor output, comparator linearity compensation two implementation methods, the introduction of the microcontroller and the temperature sensor, to achieve the linearity compensation of the gyro output signal. The experiments show that: after compensation, the non-linearity of the fluidic gyroscope5%down to 0.5%, to-120°/s~+120°/s measurement range from-40°/s~+40°/s Fluidic gyroscope linearity compensation with low non-linearity, wide measuring range.

• Periodical: Advanced Materials Research (Volumes 756-759)
• Pages: 4221-4224
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.756-759.4221
• Online since: September 2013
• Authors: Chuan Zhi Mei, Lin Hua Piao, Bao Li Zhang
• Keywords: Fluidic Gyroscope, Linearity, Software Compensation, Thermal Components

References

[1] Van Thanh Dau, Otake Tomonori, Thien Xuan Dinh, et al. A Multi Axis Fluidic Inertial Sensor,A. IEEE Sensors Conference[C]. Lecce, 2008: 666-669.

DOI: 10.1109/icsens.2008.4716529

[2] V.T. Dau, T. Otake, T.X. Dinh, et al. Design and fabrication of convective inertial sensor consisting of 3DOF gyroscope and 2DOF accelerometer,A. Actuators and Microsystems Conference[C]. Denver, 2009, 1170-1173.

DOI: 10.1109/sensor.2009.5285911

[3] Thien Xuan Dinh, Van Thanh Dau, Susumu Sugiyama, et al. Fluidic device with pumping and sensing functions for precise flow control,J. Sensors and Actuators B: Chemical, 2010, 150(2): 819-824.

DOI: 10.1016/j.snb.2010.08.009

[4] Wang Xing, Piao Linhua, Yu Quangang, The temperature and pressure of the finite element analysis of airflow rate gyro, Journal of Beijing Information Science & Technology University Vol. 4 (2011), p.49 (In Chinese).
