Oxygen Sensor Based on Tunable Diode Laser Absorption Spectroscopy with a Vertical Cavity Surface-Emitting Laser

Abstract:

Oxygen plays a fundamental role in nature and industrial process, the fast on-line oxygen concentration detection is of great significance. Tunable diode laser absorption spectroscopy (TDLAS) is capable high selective, high sensitive, non-intrusive, this technique exploits the diode laser tunable and narrow bandwidth characteristics, by selecting one absorption line of the target gas to avoid interference from other gas and realize oxygen concentration fast on-line detection. In this paper, we use vertical cavity surface-emitting laser (VCSEL) as the light source, adopting the wavelength modulation spectroscopy and the harmonic detection technology to measure the second harmonic signal and realize oxygen concentration fast on-line detection. The detection concentration range between 0.1% to 40% and detection accuracy is 0.1%.

• Periodical: Advanced Materials Research (Volumes 760-762)
• Pages: 40-44
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.760-762.40
• Online since: September 2013
• Authors: Yan Wei Gao, Yu Jun Zhang, Dong Chen, Ying He, Kun You, Yi Zhou, Jian Guo Liu, Wen Qing Liu
• Keywords: Oxygen Sensor, TDLAS, VCSEL, WMS

References

[1] Hans P Zappe, Martin Hess, Michael Moser, Rainer Hovel, Karlheinz Kulden, Narrow-linewidth vertical-cavity surface-emitting lasers for oxygen detection, APPLIED OPTICAL, Vol. 39, pp.2475-2479, May (2000).

DOI: 10.1364/ao.39.002475

[2] David Chrisitian Hovde, and Craig A. Parsons, Wavelength modulation detection of water vapor with a vertical cavity surface-emitting laser, APPLIED OPTICS, Vol. 36, pp.1135-1138, February (1997).

DOI: 10.1364/ao.36.001135

[3] P. Vogel, V. Ebert, Near shot noise detection of oxygen in the A-band with vertical-cavity surface-emitting lasers, Lasers and optics, Applied Physcis B 72, 127, December (2000).

DOI: 10.1007/s003400000516

[4] William J. Kessler, Mark G. Allen, Steven J. Davis, Phillip A. Mulhall, and Jan A. Polex, Near-IR diode laser-based sensor for ppb-level water vapor in industrial gasers, Industrial and Environmental Monitor anf Biosensors, SPIE No. 3537-A30, November (1998).

DOI: 10.1117/12.341026

[5] Huang Wei, Gao Xiaoming, Li Xiaoyun, Li Weizheng, Huang Teng, Near-IR diode laser-based sensor for remote sensing of methane leakage, Optical applicata, Vol. XXXV, No. 1, (2005).

[6] M.B. Frish, R.T. Wainner, B.D. Green, J. Stafford-Evans, M.C. Laderer, Progress in reducing size and cost of trace gas analyzers based on tunable diode laser absorption spectroscopy, SPIE Opticas East Advanced Environmental, Chemical, and Biological Sensing Technologied II (Philadephia, PA), October (2004).

DOI: 10.1117/12.580938

[7] Daniel B. Oh, and David Christian Hovde, Wavelength-modulation detection of acetylene with a near-infrared external-cavity diode laser, APPLIED OPTICAL, Vol. 34, pp.7002-7005, October (1995).

DOI: 10.1364/ao.34.007002

[8] M.B. Frish, R.T. Wainner, M.C. Laderer, K.R. Parameswaran, D.M. Sonnenfroh, and M.A. Druy, Precision and accuracy of miniature tunable diode laser absorption spectrometers, next-generation spectroscopic technologies IV, SPIE, Vol. 8032, 803209-1, (2011).

DOI: 10.1117/12.884526
