Simulation Analysis and Benchmarking Validation of Magnetic, Electromagnetic and Hybrid Shields in Large Power Transformers

Abstract:

according to different theories the magnetic shunt, the electromagnetic shield and a combination of both in power transformer have protective shielding functions to mental components and decrease stray-field loss ( including eddy current loss and hysteresis loss), avoiding damage to insulation devices caused by partial overheating for overconcentration of the loss. This paper will build a 2D modeling and simulation which proves the improved platform measuring the the shield loss and flux density of the transformer product model can provide a more reasonable flux complementary condition. Three kinds of shield in the model will be calculated by 3-D model simulation to research and compare the loss and flux density of the magnetic shunt, the electromagnetic barrier and the hybrid shield, which is of significant analyzable and referable value for optimizing the design of magnetic shields in large power transformers.

• Periodical: Advanced Materials Research (Volume 873)
• Pages: 871-876
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.873.871
• Online since: December 2013
• Authors: Yue Ning Li*, Yong Gang Li, Zhi Guang Cheng
• Keywords: Electromagnetic Shield, Flux Density, Hybrid Shield, Magnetic Shunt, Stray-Field Loss

References

[1] Z. Cheng, N. Takahashi, B. Forghani, et al: 3-D finite element modeling and validation of power frequency multi-shielding effect. IEEE Trans on Magn. Vol. 48(2012) No. 2, pp.243-246.

DOI: 10.1109/tmag.2011.2172580

[2] Zhang Junjie: Research on a new stray loss tester with mirror method and shielding in power transformers (MS., North China Electric Power University, China 2012), p.5.

[3] Z. Cheng, N. Takahashi, B. Forghani, et al: 3-D finite element modeling and validation of power frequency multi-shielding effect. IEEE Trans on Magn. Vol. 48(2012) No. 2, pp.243-246.

DOI: 10.1109/tmag.2011.2172580

[4] National Steel Standardization Technical Committee. Methods of measurement of the magnetic properties of electrical steel sheet and strip by means of an Epstein frame. Beijing: China Standard Press, (2008).

DOI: 10.3403/01451763

[5] Z. Cheng, N. Takahashi, B. Forghani, et al: Effect of variation of B-H properties on loss and flux inside silicon steel lamination. IEEE Trans on Magn, Vol. 47(2011) No. 5, pp.1346-1349.

DOI: 10.1109/tmag.2010.2086438

[6] Z. Cheng, N. Takahashi, B. Forghani, et al: 3-D finite element modeling and validation of power frequency imulti-shielding effect, presented at Compumag, Australia, (2011).

[7] Cheng Zhiguang, Norio Takahashi, Behzad Forghani, et al: Electromagnetic and thermal field modeling and application in electrical engineering (Science Press, China, 2009).
