Effects of Iron Dopants on Barium Strotium Titanate (Ba_0.8Sr_0.2TiO₃) Thin Films

Abstract:

BST thin films have been grown by Chemical Solution Deposition (CSD) method on the substrate of Pt/Si. The fabrication of BST doped by Fe have been successfully using spin coater with 4000 rpm during 30 second. Annealing process use the holding time at 3 hours, the heating rate at 5°C/min and temperature at 800°C. The ratio of Ba_0.8Sr_0.2TiO₃ molar and Fe variant dopant (0%, 1%, 3%, and 5%) were characterized by X-Ray Diffraction (XRD) and obtaining results that show the peak shift due to variations dope. The peak shifted to the right for each increment Fe dopant. Results of addition Fe dopant also cause a differences in the magnitude of Full Width at Half Maximum (FWHM) and lattice parameters on BST ferroelectric materials. Other characterize that has been done by Scanning Electron Microsopy (SEM), it is show the thickness of the material. The resulting lattice parameters with the General Structure Analysis System (GSAS) software analysis showed that a thin films of BST and BSTF have a tetragonal structure because it has a value of a=b≠c and α=β=γ=90⁰. Based on SEM characterization, the thickness of thin film is about 330 nm.

You might also be interested in these eBooks

Advanced Materials Science and Technology

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 896)

Pages:

229-232

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.896.229

Citation:

Cite this paper

Online since:

February 2014

Authors:

Riana Tri Setyadhani, Anif Jamaludin, Yofentina Iriani*

Keywords:

Ba_0.8Sr_0.2TiO₃, CSD, Fe Dopant, FWHM, GSAS

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Besland, M. P., Benzeggouta, D., Borderon, C., Hugon, M. C., Salimy, S., Charpentier, A. Investigation of BST thin films deposited by RF magnetron sputtering in pure Argon. Thin Solid Films (2010) 4619-4622.

DOI: 10.1016/j.tsf.2009.12.045

Google Scholar

[2] Iriani, Y., Hikam, M., Soegijono, B., & Mudzakir, I. Pengaruh Heating Rate dan Jumlah Lapisan terhadap Sifat Listrik (Kurva Histerisis) pada Lapisan Tipis Barium Strontium Titanat. Indonesian Journal of Materials Science (2008) 205-208.

DOI: 10.14203/metalurgi.v35i3.570

Google Scholar

[3] Jiangying, W., Zhang, X., Zhang, J., Li, H., & Li, Z. Dielectric and Piezoelectric Properties of (1-x)Ba0. 7Sr0. 3TiO3 - xBa0. 7Ca0. 3TiO3 Perovskite. Journal of Physics and Chemistry of Solids (2012) 957-960.

Google Scholar

[4] Xiao, L., Choy, K. -L., & Harrison, I. Co-doped BST thin films for tunable microwave applications. Surface & Coatings Technology (2011) 2989-2993.

DOI: 10.1016/j.surfcoat.2010.11.009

Google Scholar

[5] Arief, A., Irzaman, Dahrul, M., & Syafutra, H. Uji Arus-Tegangan Film Tipis BST dengan Pendadah Niobium Penta Oksida sebagai Sensor Cahaya. Prosiding Seminar Nasional Fisika. (2010).

DOI: 10.21009/03.snf2017.02.mps.03

Google Scholar

[6] Kim, J., Kim, S., Kim, W. J., Ha, T. G., Kim, I. -S., Song, J. -S., et al. Improved ferroelectric properties of Cr-doped Ba0. 7Sr0. 3TiO3 thin films prepared by wet chemical deposition. ScienceDirect (2006) 2322-2325.

DOI: 10.1016/j.matlet.2005.12.134

Google Scholar

[7] Cole, M., Joshi, P. C., Ervin, M. H., Wood, M. C., & Pfeffer, R. L. The influence of Mg doping on the materials properties of Ba1-xSrxTiO3 thin films for tunable device applications. Materials Letters (2000) 34-41.

DOI: 10.1016/s0040-6090(00)01059-2

Google Scholar

[8] Sueta, N., Iriani, Y., Hikam, M., Soegijono, B., & Jamaludin, A. Studi Kekristalan Barium Strontium Titanat (Ba0. 5Sr0. 5TiO3) yang didoping Magnesium dengan Metode Spin Coating. Indonesian Journal of Material Science , Vol 9 (2008) 245-248.

Google Scholar
