Defects Induced by Reactive Ion Etching in Ge Substrate

Abstract:

We investigated impacts of the Ar and CF₄plasma during reactive ion etching (RIE) on defect formation in the Ge substrates using the deep-level-transient-spectroscopy (DLTS) technique. It was found that the Ar plasma causes the roughening of the Ge surface. Moreover, the Ar plasma induces a defect with an energy level of 0.31 eV from the conduction band minimum in the Ge substrate, confirming by DLTS spectra. On the other hand, the CF₄ plasma hardly induces the surface roughness of Ge. However, the CF₄ plasma induces many kinds of electron and hole traps. It should be noted that the defects associated with Sb and interstitials are widely distributed to around 3-µm.
