Bulletproof and Noise-Reducing Guards in Lightweight Design for Woodworking Machines

Abstract:

At present, guards on woodworking machine tools have to undergo an impact test with a 100 g projectile and an impact speed of 70 m/s to protect the operator against breaking tools. At the moment, only sheet metal housings and plastic elements of polycarbonate as well as particular safety curtain systems meet these requirements regarding the retention capacity of machine enclosures for woodworking centres according to EN 848-3. In context of this work, a machine enclosure made out of lightweight materials was developed as alternative to the conventional sheet metal housings. A solution for safety curtains that passes easy over the workpieces without damaging the edges was also worked out. With regard to rigid guards, many different kinds of material combinations were examined concerning retention capacity and acoustic behaviour. In addition to the experimental tests, a FEM model was developed representing the impact behaviour of the composite based. Finally, a lightweight enclosure prototype was designed and examined with regard to the retention capacity at critical spots and of sound emission.

• Periodical: Advanced Materials Research (Volume 907)
• Pages: 41-54
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.907.41
• Online since: April 2014
• Authors: Uwe Heisel*, Vincenzo Forcillo
• Keywords: Composite, Machine Tool, Safety, Simulation

References

[1] Uhlmann, E.; Bold, J.; Ising, M.: Dimensioning and Design of Separating Safeguards. In: WGP-Annals, VI/2, 1999, S. 131-134.

[2] Uhlmann, E.; Wittner, M.: Development from Impact Tests to the Simulation of Damage Events of Grinding Wheels. In: Production Engineering, WGP-Annals X 1, 2003, S. 147-150.

[3] Heisel, U.; Forcillo, V.: Verbesserung des Arbeitsschutzes in der Holzbearbeitung – Durchschlagsichere und Lärm reduzierende Maschinenkapselungen für Holzbearbeitungszentren. In: wt Werkstatttechnik online, Jahrgang 101 (2011) H. 1/2, S. 10-15.

DOI: 10.37544/1436-4980-2011-1-2-10

[4] Borzelli, E.: Research on flexible curtains against ejection of part of tools in CNC boring routing machines for wood working. Vortrag vor dem Normenausschuss, Stuttgart, (2002).

[5] N. N.: EN 848-3: Safety of woodworking machines — One side moulding machines with rotating tools - Part 3: Numerically controlled (NC) boring and routing machines, (2010).

DOI: 10.3403/30107300

[6] Heisel, U.; Tröger, J.; Schneider, M.: Große Rückhaltefähigkeit: Neue Schutzvorhänge für NC-Bearbeitungszentren. In: HK Holz- und Kunststoffverarbeitung 05/2007, S. 86–88.

[7] Heisel, U.; Tröger, J.; Schneider, M.: Sichere Maschinen – Einsatz faserverstärkter Materialien zur Erhöhung der Maschinensicherheit. In: HK Holz- und Kunststoffverarbeitung 05/2008, S. 140–143.

[8] Heisel, U.; Forcillo, V.: Leicht und dennoch sicher. In: dds – Das Magazin für Möbel und Ausbau 9/2010, S. 44-45.

[9] Wittner, M.: Leichtbau im Maschinenschutz - Umsetzungsstrategien und Konzepte, Dissertation Technische Universität Berlin, (2007).

[10] Uhlmann, E.; Bleck, W.; Duchstein, B.; Labudde, T.; Wildau, M.: Austenitische Edelstähle für trennende Schutzeinrichtungen. In: wt Werkstatttechnik online, Jahrgang 100 (2010) H. 7/8, S. 565-571.

DOI: 10.37544/1436-4980-2010-7-8-565

[11] Mewes, D.; Trapp, R. -P.: Impact Resistance of Materials for Guards on Cutting Machine Tools - Requirements in Future European Safety Standards. In: International Journal of Occupational Safety and Ergonomics (JOSE) 6, H. 4, 2000, S. 507-520.

DOI: 10.1080/10803548.2000.11076469

[12] Knorr, W.: Sicherheitstechnische Optimierung und Beurteilung von Schutzvorhangsystemen für Holzbearbeitungszentren, Dissertation Universität Stuttgart, (2007).

[13] Heisel, U.; Forcillo, V.: Schutz vor fliegenden Werkzeugbruchstücken. Teil 1. In: HK Holz- und Kunststoffverarbeitung 03/2011, S. 80-85.

[14] Heisel, U.; Forcillo, V.: Schutz vor fliegenden Werkzeugbruchstücken Teil 2. In: HK Holz- und Kunststoffverarbeitung 04/2011, S. 110-113.

[15] N.N.: EN ISO 7235: Acoustics - Laboratory measurement procedures for ducted silencers and air-terminal units - Insertion loss, flow noise and total pressure loss, (2003).

DOI: 10.3403/02884767

[16] N.N.: DIN ISO 3741: Acoustics - Determination of sound power levels and sound energy levels of noise sources using sound pressure - Precision methods for reverberation test rooms, (2010).

DOI: 10.3403/30147252

[17] Uhlmann, E.; Marcks, P.: Analysis of the Design of Machineguard Windows using FEM. In: Production Engineering Research Development 13 (1), 2006, S. 211-214.

[18] Mewes, D.; Trapp, R. -P.: Protect Machine Operators. In: manufacturing engneering 124, H. 3, 2000, S. 118-130.

[19] N. N.: EN ISO 3746: Acoustics - Determination of sound power levels and sound energy levels of noise sources using sound pressure - Survey method using an enveloping measurement surface over a reflecting plane, (2010).

DOI: 10.3403/30094857
