Magnetic Pulse Spot Welding: An Innovative Approach

Abstract:

The magnetic pulse welding is a rapid process (takes place within few micro seconds) that joins both homogeneous and heterogeneous materials in the solid state. The process involves applying variable high current on an inductor to generate Lorentz forces on to the conductive primary part (flyer). To realize the weld it is necessary to accelerate the flyer to impact on to the secondary stationary part (base material) at a very high velocity attained over the distance, called air gap, between the parts. It is typically possible to perform welding of tubes and sheets provided there is an optimized air gap between the parts to be welded. As part of our work we have developed an innovative approach (Magnetic Pulse Spot Welding-MPSW) that eliminates the delicate task of maintaining the aforementioned air gap between the plates. The proposed method opens better viable perspectives for heterogeneous assembly of automotive structures or connecting batteries in a quasi-cold state. The developed approach has been validated on the heterogeneous assembly Al/Fe by tensile tests (quasi-static and dynamic) that attested the quality of welds.

• Periodical: Advanced Materials Research (Volume 922)
• Pages: 481-486
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.922.481
• Online since: May 2014
• Authors: Arun Prasath Manogaran*, Prabu Manoharan, Didier Priem, Surendar Marya, Guillaume Racineux
• Keywords: Heterogeneous Materials, Magnetic Pulse Welding, Spot Welding, Wavy Interface

References

[1] M. A. Al-Jader, N. Wylie, J.D. Cullen and A.I. Al-Shamma'a, Investigation into Spot Welding Process Sustainability for the Automotive Industry, 5th annual conference on BEAN (Built Environment & Natural Environment), Liverpool john Moores University, 2010.

[2] Daniel Carle, Gordon Blount, The suitability of aluminum as an alternative material for car bodies, Materials and Design, Volume 20, Issue 5, 267 – 272, 1999.

DOI: 10.1016/s0261-3069(99)00003-5

[3] The Aluminium Association, Inc.: Aluminium industry roadmap for the automotive market: enabling technologies and challenges for body structures and closures, May, 1999.

[4] Kawalla, R., Lehmann, G., Ullmann, M.: Magnesium semi-finished products for vehicle construction, Archives of Civil and Mechanical Engineering, 2008, Vol. 8, No. 2, p.93–101.

DOI: 10.1016/s1644-9665(12)60196-4

[5] Information on http://www.keytometals.com/page.aspx?ID=CheckArticle&site=ktn&NM=152, Welding of dissimilar materials, Key to metals, Aug 2006.

[6] J. Verstraete, W. De Waele, K. Faes, Magnetic pulse welding: lessons to be learned from explosive welding, Sustainable Construction and Design, 469 -475, 2011.

DOI: 10.21825/scad.v2i3.20545

[7] I. Masumoto, K. Tamaki, M. Kojima, Electromagnetic welding of aluminum tube to aluminum or dissimilar metal cores, Transactions of the Japan welding society, Vol. 16, No. 2, Oct 1985.

[8] S. Marya, G. Racineux, M. Marya, F. Gratecap, Exploring magnetic pulse welding of dissimilar metals: Welding of axisymmetric aluminum -copper parts, 2nd International symposium on smart processing technology, Nov (2007)

DOI: 10.3390/jmmp4030069

[9] Aizawa T., Methods for electromagnetic pressure seam welding of Al/Fe sheets, Weld. Int. 18 (11), 868–872, 2004.

DOI: 10.1533/wint.2004.3346

[10] Aizawa T., Kashani M., Okagawa K., Application of Magnetic Pulse Welding for Aluminum Alloys and SPCC Steel Sheet Joints, Welding Journal, 86, 119 – 124, 2007.

[11] T. Aizawa, K. Okagawa, M. kashani, Taizawa, Multi-Spot Welding by Applying Magnetic Pressure, 2009.
