Shear Strength Prediction of Reinforced Concrete Deep Beams Using Strut-and-Tie Model

Abstract:

Shear strength prediction of simple deep reinforced concrete beams by method of strut-and-tie model is presented in this paper. The tested specimens were designed according to Appendix A of ACI 318-11 code with variations of shear span-to-effective depth ratios and ratios of horizontal and vertical crack-controlling reinforcement. Test results revealed that at the same shear span-to-effective depth ratio, the various crack-controlling reinforcements significantly influenced on strength reduction coefficients of strut and failure modes. When the shear span-to-effective depth ratios were increased, failure modes changed from splitting diagonal strut to flexural-shear failure. Based on the test results, the proposed model was compared with Appendix A of ACI 318-11code.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 931-932)

Pages:

468-472

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.931-932.468

Citation:

Cite this paper

Online since:

May 2014

Authors:

Piyoros Tasenhod*, Jaruek Teerawong

Keywords:

Crack-Controlling Reinforcement, Failure Mode, Shear Strength, Strut-and-Tie Model

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] ACI Committee 318, Building Code Requirements for Structural Concrete (ACI 318M-11) and Commentary, Farmington Hills, (2011).

Google Scholar

[2] J.G. MacGregor, K.J. Wight, Reinforced concrete mechanics and design, fourth ed., Prentice-Hall International Inc, London, (2005).

Google Scholar

[3] American Association of State Highway and Transportation Officials, AASHTO LRFD Bridge Design Specifications, second ed., Washington DC, (1998).

Google Scholar

[4] T.T.C. Hsu, Unified theory of reinforced concrete, CRC Press, Florida, (1993).

Google Scholar

[5] C.G. Quintero-Febres, G. J. Parra-Montesinos, Wight. J.K., Strength of struts in deep concrete members designed using strut-and-tie method, ACI Structural Journal. 103 (2006) 577-86.

DOI: 10.14359/16434

Google Scholar

[6] G. Aguilar, A. B. Matamoros, G. J Parra-Montesinos, J. A. Ramirez, and J. K. Wigth, Experimental Evaluation of Design Procedures for Shear Strength of Deep Reinforced Concrete Beams, ACI Structural Journal. 99 (2002) 539-48.

DOI: 10.14359/12123

Google Scholar

[7] K. Tan, H. Lu, Shear Behavior of Large Reinforced Concrete Deep Beams and Code Comparisons, ACI Structural Journal. 99 (1999) 836-46.

DOI: 10.14359/738

Google Scholar

[8] J.W. Park, D. Kuchma, Strut-and-tie model analysis for strength prediction of deep beams, ACI Structural Journal. 104 (2007) 657-66.

DOI: 10.14359/18947

Google Scholar

[9] G. Russo, R. Venir, M. Pauletta, Reinforced concrete deep beams-Shear strength model and design formula, ACI Structural Journal. 102 (2005) 913.

DOI: 10.14359/14414

Google Scholar

[10] J.W. Dally, F.R. William, Experimental stress analysis, McGraw-Hill, Boston, (1993).

Google Scholar

[11] J.G. MacGregor, K.J. Wight, Reinforced concrete mechanics and design, Discontinuity Regions and Strut-and-Tie Models, Prentice-Hall International Inc, London, 2005, pp.879-972.

Google Scholar

[12] J. Lee, U. Kim, Effect of Longitudinal Tensile Reinforcement Ratio and Shear Span-Depth Ratio on Minimum Shear Reinforcement in Beams, ACI Structural Journal. 105 (2008) 134-44.

DOI: 10.14359/19728

Google Scholar

[13] K. Tan, F. Kong, S. Teng, L. Weng, Effect of Reinforcement on High-Strength Concrete Deep Beams, ACI Structural Journal. 94 (1997) 572-82.

Google Scholar
