Design and Realization of Substation-Control Center Two Level Distributed Alarming System

Abstract:

This paper proposes the construction mode of a two-level distributed alarming system, in which alarms are coordinately processed by substations and control center. In substation side, we classify alarms into several grades according to the degree of their importance and send the extracted key alarms to control center, thus reduce the amount of alarm passing and ensure the transmission reliability and speed; meanwhile, we carry out alarm verification and pretreatment through information redundancy to validate alarm correctness. In control center side, we integrate the data of ordinary Supervisory Control and Data Acquisition (SCADA) and the alarms received directly from substations, and carry out comprehensive fault reasoning and correctness verification. In order to illustrate the feasibility of the substation-control center distributed alarming system, the overall structure, substation smart alarm (SSA), control center smart alarm (CCSA) and cooked data transmission of this construction mode will be discussed in detail.

• Periodical: Advanced Materials Research (Volume 933)
• Pages: 789-793
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.933.789
• Online since: May 2014
• Authors: Wei Jin Zhuang*, Hai Bing Zhu, Jia Qing Zhao, Yong Gang Zhang, Ming Yang Sun
• Keywords: Alarm Direct Passing, Fault Reasoning, Information Interchange, Smart Alarm

References

[1] Y. Wu, M. Kezunovic, T. Kostic, An Advanced Alarm Processor Using Two-level Processing Structure, Power Tech 2007, Lausanne, Switzerland, July (2007).

DOI: 10.1109/pct.2007.4538304

[2] Hongbin Sun, Boming Zhang, Wenchuan Wu, etc, Smart Control Center targeted at China Smart Grid [J]. Journal of Power Science and Technology. 2009(6).

DOI: 10.1109/isgt-asia.2012.6303117

[3] Qingxin Li, Dexing Wang, Hongbin Sun, etc, Engineering Practice and Benefit Analysis of Substation State Estimation [J]. Power System Protection and Control. 2012(6).

[4] Qingxin Li, Hongbin Sun, Jing Wang, etc, Substation-Control Center Two Level Distributed State Estimation [J]. Power System Automation. 2012(4).

[5] M. Kezunovic, P. Spasojevic, C. Fromen, D. Sevcik, An Expert System for Transmission Substation Event Analysis, IEEE Transactions on Power Delivery, Vol. 8, No. 4, pp.1942-1949, October (1993).

DOI: 10.1109/61.248306

[6] Chuangxin Guo, Zhenxing Gao, Yi Liu, etc, Multi-source Information Fusion Power Grid Fault Diagnosis Method [J]. High Voltage Technology. 2010(12).

[7] ErXi Wang, Yuan Zhang and Jie Wu, Research on Smart Alarm Application of Shanghai Power Grid Dispatching Automation System [J]. East Chin Electric Power. 2012(5).
